23 EKI-1351/EKI-1352/EKI-1521/1522/1524 User Manual
Chapter 2 Getting Started
2.3.1.2 DIN-rail Mounting
You can mount the EKI serial device server on a standard DIN rail. The DIN-rail kit is
screwed on the industrial switch when out of factory. If the DIN-rail kit is not screwed
on the industrial switch, please screw the DIN-rail kit on the switch first.
First, hang the EKI serial device sever to the DIN-rail with angle of inclination. See
below figure.
Figure 2.14 DIN-rail Step 1
Then, let the device down straight to slide over the rail smoothly.
Figure 2.15 DIN-rail Step 2
2.3.2 Network Connection
EKI-1521, EKI-1522, and EKI-1524 has 2x RJ-45 that support connection to 10 Mbps
Ethernet, or 100 Mbps Fast Ethernet, and half or full duplex operation. EKI-1521,
EKI-1522 and EKI-1524 can be connected to other hubs or switches through a
twisted-pair straight through the cable or a crossover cable up to 100m long.
