Chapter 1 General information 3
Specifications
Digital output
32 optically-isolated outputs
• Output voltage: Open collector 5 to 40 V
DC
• Sink current: 200 mA max.
• Isolation voltage: 1,000 V
DC
Register format
BASE+0 Isolated DO0~DO7
BASE+1 Isolated DO8~DO15
BASE+2 Isolated DO16~DO23
BASE+3 Isolated DO24~DO31
Dimensions
185 mm x 100 mm
Connectors
DB-37 connector for isolated Digital Output
Power consumption
+5 V: 330 mA typical, 500 mA maximum
Daughterboards
PCLD-880
The PCLD-880 is a universal screw terminal board for industrial
wiring. It can be used with the analog or digital ports of various PC-
LabCards via 20-pin flat cables or shielded round cables with DB-37
connectors.
