Advantech UNO-2484G V2 Startup Manual

UNO-2484G V2 Startup Manual 5
4. Close the rear cover and re-attach the six screws back
(PN:1930001361*6pcs).
Installing 2.5” SSD Module
1. Remove the six screws (PN:1930001361*6pcs) on the
rear cover.
2. Remove SSD bracket (PN:1960084377N000*1pcs) and
screws (PN:1930008481*4pcs).
SimpleMaintenanceProcess(Cont.)
3. Assemble the SSD on the bracket with screws
(PN:1930001361*4pcs).
4. Assemble the SSD with bracket on the system slide rail.
5. Re-attach the SSD bracket with screws
(PN:1930008481*4pcs).
SimpleMaintenanceProcess(Cont.)
