Controls and Indicators
True Online 1-3k UPS User Manual
13
Input information Input voltage(VAC),
Input frequency(Hz),
Input current(A)
Warn information
Fault code(FAULT),
Warn code(WARN),
working mode(First number:
n-normal mode, E-ECO
mode. Second number: rated
voltage and frequency
0-200V/50Hz, 1-200V/60Hz,
2-208V/50Hz, 3-208V/60Hz,
4-220V/50Hz, 5-220V/60Hz,
6-230V/50Hz, 7-230V/60Hz,
8-240V/50Hz, 9-240V/60Hz)
mute on( ), mute
off( )
Battery information Battery voltage(VDC),
Capacity(%) if needed,
Firmware version,
Battery low warn(LOW)
UPS ID(1-9) in setting mode
Load information Load percent(%)
Active load(kW)
Apparent load(kVA)
Protocol code in setting
mode
Output information Output voltage(VAC)
Output frequency(Hz)
Output current(A)
Note: Press “FUNC” button to see different information.
