6 True Online 1-3k UPS User Manual
4. Product Specification and performance
4.1 Model Description
This manual is applicable to the following models:
“L” Model: Long backup time,
4.2 Product Specification and Performance
1. General Specification
Model 1K 2K 3K
Power Rating
1000VA/
800W
1000VA/
900W
2000VA/
1600W
2000VA/
1800W
3000VA/
2400W
3000VA/
2700W
Frequency (Hz)
50/60 50/60 50/60
Input
Voltage
110Vac~288Vac
Current
6A max. 10A max 16A max
Battery
Voltage
24VDC
36VDC
48VDC
72VDC
72VDC
96VDC
Numbers
2 3 4 6 6 8
Current
50A max
35A max
50A max
35A max
50A max
37A max
Output
Voltage
200V/208V/220V/230V/240V
Dimension
(WxDxH) mm
144*353*222 190*374*336
190*426*
336
Weight
(kg)
Standard
10 10.5 17 21 22 24.5
Long 5 6 8.5 11 9.5 12
Model No. Type
IST3010-IST3020-IST3030
Standard model
IST3010-L IST3020-L IST3030-L
Long backup model
