Setting Setting
42
43
PV input mode：
Battery parameters：
Enter password
Press ENTER button
Enter password
Setting
1System setting
Press ENTER button
Press ENTER button
6 PV input type
Select the proper mode
based on the requirements
of components
Setting
Press ENTER button
2Battery
parameters
Refer to menu 8.2.2and
set up according to
actual battery needs
Press ENTER
button
Peak load shifting：
After finishing the setting of Peak load shifting mode, the charging and
discharging time also need to be set up.
Note: an interface If the time is set up incorrectly, the system willpop up indicating
the setting error. Charging and discharging time will return to the state prior to setting.
Press ENTER button
Press ENTER button
Setting
Enter password
Press ENTER button
1System setting
Press ENTER button
1Working mode
Press ENTER button
2 Peak load
shifting
Restart
Refer to 8.2.1and
set up the time
according to needs.
(2) Select the corresponding mode based on actual situation
Self-generation and self-consumption（system default mode）
After the Restart interface appears, the machine will return to the selection
interface of three working modes;
If more items are to be set up, restart after fini shing the setting.
Battery priority：
Note:When choosing battery priority mode, the corresponding charging
current should be opted for according to the battery type. The system default
current is 20A.
Press ENTER button
Enter password
Press ENTER button
Press ENTER button
Press ENTER button
Enter password
Press ENTER button
Setting
1System setting
Press ENTER button
1Working mode
1 Self-generation and
self-consumption
Restart
Setting
1System setting
Press ENTER button
1Working mode
Press ENTER button
3Battery priority
Restart
