8 LCD Operation
44
45
LCD Operation
LCD Operation
8.1.1PV1 input display interface
Interface
PV1 INPUT
VOLT： 33.8V
CURR： 0.00A
POWER： 0W
PV1 input real-time voltage
PV1 input real-time current
PV1 input power
8.1.2 PV2 input display interface
8.1.3 Bus voltage
8.1.4 Battery
Interface
Interface
Interface
PV2 INPUT
VOLT： 49.8V
CURR： 0.00A
POWER： 0W
PV2 input real-time voltage
PV2 input real-time current
PV2 Input power
Bus voltage of the system
DC VOLTAGE
BUS： V
BATTERY
VOLT： 42.2V
CURR： 20.2A
Battery input voltage
Battery current (+ means discharge,
- means charge)
8.1.5 BMS parameters
8.1.6 BMS parameters
8.1.7 Grid-connected output
8.1.8 Inverter output
Interface
Interface
Interface
Interface
Battery type：(lead acid, lithium battery)
Battery temperature
Percentage of battery surplus capacity
BATTERY PRMETER
TYPE： LEAD-ACID
TEMP： ℃ 0 .0
SOC： 60%
BMS PRMETER
CHAR VOLT： 54.5V
CHARGE： 25A
DISCHA： 100A
Battery charging voltage
Battery charging current: select according
to battery type
Battery discharging current
GRID OUTPUT
VOLT： 0.0V
CURR： 0.00A
FREQ： 0.00Hz
Mains Real time voltage
CT real-time current
Grid-connected real-time frequency
INV OUTPUT
VOLT: 0.0V
CURR: 0.00A
FREQ: 0.00HZ
Inverter real-time voltage
Inverter real-time current
Inverter real-time frequency
