AEC R5KL1 - 8.1.13 Status information; 8.1.14 Error information

LCD Operation
LCD Operation
46
47
8.1.9 Load
8.1.10 Power
8.1.11 Power
8.1.12 Temperature
Interface
Interface
Interface
Interface
Emergency load (BACKUP) voltage
Emergency load (BACKUP) current
Percentage ratio of load to rated road
LOAD
VOLT: 0.00V
CURR: 0.00A
PERCENT: 80%
POWER
PV I/P： W
LOAD： W
BAT： W
PV real-time total power
BACKUP real-time load
Battery real-time load（+ means discharge,
- means charge）
Real-time temperature of inverter system
Real-time temperature of Bidirectional
DCDC system radiator
Internal ambient temperature
TEMPERATURE
INVER： 25 ℃
DCDC： 26 ℃
INSIDE： 27 ℃
POWER
INV: W
GRID: W
Inverter real - time total power
CT real-time total power
8.1.13 Status information
8.1.14 Error information
Interface
8.1.15 System setting
Interface Description
Status mode:Self-generation and self-consumption
,Peak load shifting and Battery priority
Grid-connection standards :China,Germany,
PV input mode：independent connection，
independent connectionconstant voltage.
，
Interface Description
System information:Power-up mode,standby mode,
hybrid grid-connection,off-grid operation,mains
charging mode, PV charging mode,bypass mode,
fault mode, DSP programming, ARM programming
INV:standby mode, off-grid inverter mode,
grid-connected mode, and transition of grid-connect
to off-grid, transition of off-grid to grid mode
DCDC:standby mode, soft start mode, charging
mode, discharging mode
STATE
SYS： ERROR
INV： STANDBY
DCDC： STANDBY
Alarm code（ see Chapter 9）
Error code（see Chapter 9）
ERROR NO.
WARNING： W11-1
FAULT： F10-1
SYSTEM
STATE:PEAKS HIFT
GRID STD: China
PV I/P： INDEPN
radiator
Australia, Italy, Spain, UK,Hungary, Belgium,
Western Australia,Greece, France, Bangkok,
Thailand, local and 60 HZ.
