LCD Operation Setting
48
49
Press ESC button to enter user setting
8.1.16 User setting
Interface Description
Press ESC on the Main Display Interface to enter
the user interface
See chapter 8.2 for more setting details
Enter the password before setting up the user
Interface Description
After entering the setup interface, the system
will prompt to input password;
The default password is “000000”, which can be
altered in Password setting menu (refer to7.4.7);
Press UP/DOWN button to increase or decrease
the figure that is input;
Press ENTER button to move the cursor
backwards or confirm the setting;
Press ESC button to move the cursor forward.
--USER--
→1：SETUP
2：INQUIRE
3：STATISTIC
--PASSWORD--
INPUT： XXXXX
8.2 Setting
Interface Description
This interface is used for various information
inquiry options.
Press UP/DOWN button to move the
corresponding options.
Press ENTER to enter the selected menu.
Press ESC button to return to the user interface.
(refer to 8.1.16)
There are 13 options in total, including system
mode, battery parameters, grid standard,
parameters, 485 operation address, 485 baud
language display, rate, LCD backlight,date/time,
clear history,password setting and maintenance,
and factory setting.
8.2.1 System setting
Interface Description
This interface is used to access system
information.
Press UP/DOWN button to move corresponding
options.
Press ENTER to enter the selected menu.
Press ESC button to return to the setting
interface. (refer to 8.3.1)
There are 8 options in total, including working
mode, PV input type, antireflux
enable, DRM enable , wake-up enable, EPS
enable, program controlled enable and boot
delay time.（see from ① to ⑧）
--SETUP--
→ 1：SY
S SETTING
2：BAT SETTING
3：GRID STD
4：RUN SETTING
5：485 ADDRESS
6：BAUD RATE
7：
LANGUAGE
8：BACKLIGHT
9：DATE/TIME
10：CLEAR REC
11：PASSWORD
12：MAINTENANCE
13：FCTRY RESET
--SYS SETTING--
→1: WORK
MODE
2: PV INPUT
3: RCur ENABLE
4: DRM ENABLE
5: BAT WAKE-UP
6:
EPS ENABLE
7: REMOTE CTRL
8: START DELAY
To Next Page
