Setting Setting
50
51
① Working mode
Interface Description
This interface is used to opt for the working mode.
After selecting the three modes, the restart
interface will be entered.
Press ESC button to return to setting interface.
( refer to 8.2.1)
After completing the setup of peak load shifting mode, the time for charging and
discharging also needs to be set.
Time setup
Interface Description
This interface is used to opt for the time of peak
load shifting
Press UP/DOWN button to move the
corresponding options.
Press ENTER to enter the selected menu.
Press ESC button to return to the working mode
interface.
② Input mode
Interface Description
Setup of PV Input mode.
The factory setting by default is standalone mode.
When parallel input is set to be stand-alone mode,
PV power will be imbalanced.
--WO R K E M ODE --
1:SELF COMSUME
→ 2:PEAK SHIFT
3: BAT PRIORITY
CHAG START: 00：00
CHARGE END: 00：00
DISC START: 00：00
DISCHA END: 00：00
--INPUT MODE--
→1: INDEPENDANT
2：PARALLEL
3: CV
③ Program controlled enable
Interface Description
back-flow-prevention function.
Default option is disabling.
④ DRM enable
Interface
Description
It is enabled when BACKUP load needs power.
Default option is disabling.
⑤ Batt ery w ake up ena ble
Interface
Description
Battery wake-up enable setting.
The default option is disabling.
⑥ Backup enable
Interface Description
It is enabled when BACKUP load needs power.
Default option is Enabling.
--BAT WAKE-UP--
→1: D
ISABLE
2: ENABLE
-- RCur ENABLE --
→1: D
ISABLE
2: ENABLE
--DRM ENABLE--
→1: DISAB
LE
2: ENABLE
--EPS ENABLE--
→1: DISAB
LE
2: ENABLE
