AEC R5KL1 - 8.2.2 Battery parameters

Setting Setting
52
53
⑦ Program controlled enable
Interface Description
The power switch of the machine can be realized
through remote control.
Default option is disabling.
⑧ Grid connecting time delay
Interface Description
The input value ranges from 20 to 300,which
with different standards.varies
8.2.2 Battery parameters
Interface Description
This interface is used to select battery parameters.
Press UP/DOWN button to move corresponding
options;
Press ENTER button to enter the selected
menu;
Press ESC button to return to setting
interface (refer to 8.3.1).
（see from ① to ③）
START-UP DELAY
INPUT: 30
UNIT: SEC
--BAT SETTING--
→ 1:BAT TYPE
2:DISC-DEPTH
3:CHARGE-CURR
--REMOTE CTRL--
→1: DISABLE
2: ENABLE
① Battery type
Interface Description
This interface is used to select battery type.
Press UP/DOWN button to move corresponding
options;
Press ENTER button to enter the selected menu
Select the OTHER_Li enter button to enter the
OTHER_Li interface;
Select the LEAD-ACID enter button to enter the
LEAD-ACID interface;
Select the PYLON_Li enter button to enter the
restart interface.
Othe r L i ba tte ry para mete r
Interface Description
This interface is used to select other Li battery
parameter.
Press UP/DOWN button to move corresponding
options;
Press ENTER button to enter the selected menu;
Options include battery charge voltage,
battery discharge end voltage and battery
over voltage protect.(see from④to⑥)
--BAT TYPE--
1: LEAD-ACID
→2: O
THER_Li
3: PYLON_Li
--OTHER LI BAT--
→1:CHARG-VOLT
2:BAT END VOLT
3:BAT OVP
