AEC R5KL1 - Page 29

Setting
54
55
Setting
Lead-acid battery parameter
Interface Description
This interface is used to select other Li
battery parameter.
Press UP/DOWN button to move corresponding
Press ENTER button to enter the selected menu;
Options include battery charge voltage,
battery capacity battery discharge end
voltage, battery over voltage protect .(see from ④
to⑦)
② Discharge depth
Interface Description
Press UP/DOWN to increase or decrease the
input figure;
Press Enter to move cursor backward,
confirm input and return to battery
parameters interface;
Press ESC to move cursor forward and return
to battery parameters interface;
The value ranges between 10% and 100%.
③ Charge current
Interface Description
Press UP/DOWN button to increase or
decrease the input figure;
Press Enter to move cursor backward,
confirm input and return to battery
parameters interface;
Press ESC button to move cursor forward
and return to battery parameters interface.
--LEAD-ACID --
→1:CHARG-VOL
T
2:EQUAL VOLT
3:BAT CAP
4:BAT END VOLT
5:BAT OVP
--DISC DEPTH--
INPUT： 60
UNIT： %
--CHARGE CURR--
INPUT： 25
UNIT： A
④ Charge voltage
Interface Description
Press UP/DOWN button to increase or
decrease the input figure;
Press Enter button to move cursor
backward, confirm input and return to
battery parameters interface;
Press ESC button to move cursor forward
and return to battery parameters interface.
⑤ Battery cutoff voltage
Interface Description
Press UP/DOWN button to increase or
decrease the input figure;
Press Enter to move cursor backward,
confirm input and return to battery
parameters interface;
Press ESC button to move cursor forward
and return to battery parameters interface.
⑥ Over-voltage Protection Point
Interface Description
Press UP/DOWN button to increase or
decrease the input figure;
Press Enter button to move cursor
backward, confirm input and return to
battery parameters interface;
Press ESC button to move cursor forward
and return to battery parameters interface.
--CHARGE VOLT--
INPUT 56.5
UNIT: V
--BAT END VOLT--
INPUT： 43.2
UNIT： V
--BAT OVP--
INPUT： 57.5
UNIT： V
options;
