1.1 Scope of Validity
This manual is an integral part of Selfnergy M-Hybrid, It describes the assembly,
installation, commissioning, maintenance and failure of the product. Please read it
carefully before operating.
1 Notes on this Manual
Notes on this ManualContents
Danger！
“Danger” indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
Note！
“Note” provides tips that are valuable for the optimal operation of our
product.
Warning!
“Warning” indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
Caution！
“Caution” indicates a hazardous situation which, if not avoided, could result
in minor or moderate injury.
R3KL1 R5KH1 R10KH3-ER5KH1-A
R3KH1 R8KH3 R20KH3-E20R5KH1-A12
R3K6L1 R10KH3 R5KL1-E
R3K6H1 R20KH3 R5KH1-E
R4K6L1 R5KL1-A R5KL1-E12
R5KL1 R5KL1-A12 R5KH1-E12
03
7. Setting
7.1 Control Panel
7.2 Instructions for LED Indicator
7.3 Instructions for the use of three modes
8 LCD Operation
8.1 LCD Operation
8.2 Setting
10 Fault diagnosis and solutions
42
42
43
43
6.5 Meter Connection
6.6 LAN Connection
6.7 DRM Connection
6.8 WiFi Connection(optional)
6.9 RF Connection(optional)
6.10 Inverter Manipulation
32
34
35
36
37
38
46
46
51
69
02
Naming rules ，For example . ：R4K6H1-A12
“
R” means “ series”.
“
“
4K6、5K” means “output power 4.6kw or 5kw ”.
“H” means “High battery voltage”，“L” means “48V Battery Voltage”.
“
1、3” means “Output single-phase (1) or three-phase (3).
“-A “means ”All in one system”. “ 12 “means ”Battery capacity 12 kWh ”.
Store this manual where it will be accessible at all times.
1.2 Target Group
This manual is for qualified electricians. The tasks described in this manual only
can be performed by qualified electricians.
1.3 Symbols Used
The following types of safety instructions and general information appear in this
document as described below:
