• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
2.7 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
3. PRODUCT DESCRIPTION
3.1 General overview
1
2
3
4
5
5
6
5
4
3
2
1
7
3
2
1
4
1
Control panel and hob
2
Air vents for the cooling fan
3
Heating element
4
Lamp
5
Shelf support, removable
6
Fan
7
Shelf positions
3.2 Cooking surface layout
180 mm
145 mm210 mm
140 mm
145 mm
1
3
456
2
1
Cooking zone 1200 W
2
Steam outlet - number and position
depend on the model
3
Cooking zone 1800 W
4
Cooking zone 1200 W
5
Residual heat indicator
6
Cooking zone 1000 / 2200 W
ENGLISH 7
