AEG 88101 - Control Point Illustrations

13 599 519 523 EN
DGS-TDS
21.04.08
2.8 Control Point Illustrations
A
ir -
inlet
Min. 20mm
Min. 5 mm
Ov en
Remark: if there is no ventilation gap in the front it’s still possible to operate the hob. Only with longer useage ( >15 min. ) the
performance will drop. For Mixed hob this is e.g. – 20%, for full induction hobs it’s higher.
(2) Pin 1, 3
(1)
(3)
(4)
(5)
Terminal
1
2
3
4
5
