AEG AC30100S - Page 3

3
3
1
2
1
3
2
3
1
Fig. 2
Fig. 1
Fig. 4
Fig. 5
Fig. 3
12
10
14
7
8
9
4
3
5
6
1
11
13
2
1 - Wheel
2 - M10 step bolt
3 - Ø10 washer (4mm)
4 - Ø10 washer (1.5mm)
5 - Ø10 spring washer
6 - M10 hex nut
5
4
3
6
1
2
1 - Air filter assembly
1 - Front handle
2 - Handle slot
3 - Bolt
1 - Wheel
2 - M6 bolt
3 - M6 hex nut
1 - Air filter assembly x3
2 - Pressure relief valve
3 - Front handle
4 - Power cord
5 - AUTO/OFF switch
6 - Pressure regulator knob
7 - Tank pressure gauge
8 - Regulator pressure gauge
9 - Quick connect coupler
10 - Tank
11 - Wheel lock x2
12 - Front wheel x2
13 - Rear wheel x2
14 - Rear handle
15 - Drain valve
15
