3
3
1 - On/off switch
2 - Front handle
3 - Tank pressure gauge
4 - Regulator pressure gauge
5 - Quick connect coupler
6 - Pressure regulator knob
7 - Pressure relief valve
8 - Rubber foot x2
9 - Wheel x2
10 - Drain valve
11 - Rear handle
12 - Oil level indicator/oil drain plug
13 - Oil cap
14 - Air filter assembly x2
15 - Reset button
1 - Air filter assembly
1 - Front handle
2 - Handle slot
3 - Bolt
1 - Rubber foot
2 - M6 flat washer
3 - M6 bolt
4 - M6 hex nut
1
2
9
2
8
14
15
11
10
12
1
3
1
Fig. 2
Fig. 1
Fig. 4
Fig. 5
6
7
4
5
3
1 - Wheel
2 - M10 step bolt
3 - M10 Washer (4mm)
4 - M10 Washer (1.5mm)
5 - Spring washer
5 - M10 hex nut
5
4
6
3
1
2
4
2
1
2
3
Fig. 3
13
