AEG AC756S - Page 4

4
4
1 - On/off switch
1 - Pressure regulator knob
2 - Quick connect coupler
1 - On/off switch
2 - Turn clockwise to increase air pressure
3 - Pressure regulator knob
4 - Turn counterclockwise to decrease air pressure
5 - Air hose
1 - Air filter housing
2 - Air filter
3 - Air filter cover
1 - Drain valve
2 - Open position
3 - Closed position
1 - Safety valve
2 - Rotate counterclockwise to release pressure
3 - Rotate clockwise to close
1
2
5
1
4
3
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6
