AEG BOBZDB - Building in

min.
3 mm
12.2 Building in
During installation in
combustible matter, NIN
SEV 1000 and fire protection
guidelines and regulations
of the Association of
Cantonal Fire Insurance shall
be strictly adhered to.
1. Place the appliance in front of the
recess and connect the mains plug.
Make sure the cable is free when you
slide the appliance.
2. Push the appliance into the recess.
A = appliance, N = recess
A A
A
B
115 mm
20
mm
442
mm
180
mm
N 560-568 mm
A 592 mm
A 567
mm
N min.
550 mm
A 595
mm
N
585-592 mm
~50
mm
3. Use a minimum of 2 screws to attach
the oven on the 2 sides (A).
www.aeg.com
30
