3. PRODUCT DESCRIPTION
3.1 General overview
1 3 5 6 742
8
10
9
9
11
11
1
2
3
4
12
1
2
3
4
12
8
1
Knob for the top oven functions
2
Temperature indicator / symbol for
the top oven
3
Knob for the top oven temperature
4
Power lamp for the main oven
5
Display
6
Knob for the main oven functions
7
Knob for the main oven temperature
8
Heating element
9
Lamp
10
Fan
11
Shelf support, removable
12
Shelf positions
3.2 Accessories
• Wire shelf
For cookware, cake tins, roasts.
• Grill- / Roasting pan
To bake and roast or as pan to collect
fat.
• Trivet
For roasting and grilling.
Use the trivet only with
the Grill- / roasting pan.
4. CONTROL PANEL
4.1 Buttons
Sensor field / Button Description
To set the time.
To set a clock function.
To set the time.
4.2 Display
The display works only with
the main oven.
A B C
