3. INSTALLATION
WARNING!
Refer to Safety chapters.
3.1 Hob and oven connection
type
This appliance has a yellow 1x14 pole
connector and can be connected to an
oven with a yellow 1x14 pole connector.
3.2 Before the installation
Before you install the hob, write down the
information bellow from the rating plate.
The rating plate is on the bottom of the
hob.
Serial number ...........................
3.3 Built-in hobs
First install the oven then the hob in its
cutout.
Only use the built-in hobs after you
assemble the hob into correct built-in
units and work surfaces that align to the
standards.
3.4 Assembly
R 5mm
min.
55mm
560
+1
mm
490
+1
mm
ENGLISH 7
