compliance with the current
standards and regulations
3. The outlet or omnipolar switch used
for connection is easily accessible
with the appliance installed.
You must purchase and install the power
cable. Use only a connection cable of
type H05V2V2-F T90 or its equivalent.
Make sure that the cable section is
applicable to the voltage load and the
working temperature.
The wires in the cord are coloured as
follows:
Green and yellow - Earth
Blue - Neutral
Brown - Live
WARNING!
A cut off plug inserted into a
13 amp socket is a serious
shock hazard. Ensure that
the cut off plug is disposed
of safely.
3.8 Replacement of the
connection cable
The replacement of electric
cable must be carried out
exclusively by the service
force centre or by personnel
with similar competencies, in
accordance with the current
regulations.
Make sure that the cable
section is applicable to the
voltage load and the working
temperature. The yellow/
green earth wire (B) must be
approximately 2 cm longer
than the live and neutral wire
(A).
3.9 Attaching the seal - On-
top installation
1. Clean the worktop around the cut out
area.
2. Attach the supplied thinner seal
stripe to the lower edge of the hob
along the outer edge of the glass
ceramic. Do not extend it. Make sure
that the ends of the seal stripe are
located in the middle of one side of
the hob.
3. Add some mm when you cut the seal
stripe to the length.
4. Push the two ends of seal stripe
together.
3.10 Assembly
min.
450mm
min.
650mm
min.
2mm
ENGLISH 11
