min. 2 mm
A
B
min.20 mm
(max.150 mm)
A
12 mm
28 mm
38 mm
B
57 mm
41 mm
31 mm
min. 500 mm
min. 60 mm
D
C
C. Removable panel
D. Space for connections
R 5 mm
min.
55 mm
490 mm
830 mm
600 mm
min.
38 mm
min.
2 mm
CAUTION!
Install the appliance only on
a worktop with a flat surface.
3.11 Possibilities for insertion
Kitchen unit with oven
The electrical connection of the hob and
the oven must be installed separately for
