9.2 If you cannot find a
solution...
If you cannot find a solution to the
problem yourself, contact your dealer or
an Authorised Service Centre. Give the
data from the rating plate. Make sure,
you operated the hob correctly. If not the
servicing by a service technician or
dealer will not be free of charge, also
during the warranty period. The
instructions about the Service Centre and
conditions of guarantee are in the
guarantee booklet.
10. TECHNICAL DATA
10.1 Rating plate
Model IAE84881FB PNC 949 597 523 00
Typ 62 D4A 01 CA 220 - 240 V / 400 V 2N 50 - 60 Hz
Induction 7.35 kW Made in Germany
Ser.Nr. ................. 7.35 kW
AEG
10.2 Software Licences
The software included in the hob
contains copyrighted software that is
licensed under the BSD, fontconfig, FTL,
GPL-2.0, LGPL-2.0, LGPL-2.1, libJpeg,
zLib/ libpng, MIT, OpenSSL / SSLEAY
ISC, Apache 2.0 and others.
Check the full copy of the licence in:
Menu > Settings > Service > License.
You can download the source code of
the open source software by following
the hyperlink present in the web product
page.
10.3 Cooking zones specification
Cooking zone Nominal power
(maximum heat
setting) [W]
PowerBoost
[W]
PowerBoost
maximum dura-
tion [min]
Cookware diam-
eter [mm]
Left front 2300 3200 10 125 - 210
Left rear 2300 3200 10 125 - 210
Middle front 1400 2500 4 125 - 145
Right rear 2300 3600 10 205 - 240
The power of the cooking zones can be
different in some small range from the
data in the table. It changes with the
material and dimensions of the
cookware.
For optimal cooking results use
cookware no larger than the diameter in
the table.
10.4 Food Sensor Technical
Specifications
Food Sensor is approved for use in
contact with food.
Working frequency 433,05 - 434,73
MHz
Maximum sending power 5 dBm
Temperature range 0 - 120°C
www.aeg.com32
