AEG U5 - Specifications and Data

18
INSTALLATION
14.5 Details on energy consumption
The product data complies with EU regulations relating
to the directive on the ecological design of energy related
products (ErP).
U5
236284
Manufacturer AEG Haustechnik
Load profile XXS
Energy efficiency class A
Energy conversion efficiency % 35.8
Annual power consumption kWh 515
Default temperature setting °C 52
Sound power level dB(A) 15
Option for exclusive operation
during off-peak periods
-
Daily power consumption kWh 2.42
14.6 Data table
U5
236284
Electrical data
Rated voltage V 220-230
Rated output kW 2
Rated current A 8.7
MCB/fuse rating A 10
Phases 1/N/PE
Frequency Hz 50
Hydraulic data
Nominal capacity l 5
Dimensions
Depth mm 155
Height mm 365
Width mm 230
Weights
Weight kg 2.4
Application limits
Temperature setting range °C 30-85
Max. permissible pressure MPa 0
Max. flow rate l/min 5
Versions
IP rating IP24
Type of installation Undersink
Type Open vented
Internal cylinder material PP
Thermal insulation material EPS
Casing material PS
Colour White
Connections
Power supply Power cable with standard
plug
Water connection G 3/8 A
