2. After closing the circuit breaker, if the closing electric signal is not removed in time, the internal
anti tripping controller of the circuit breaker will cut off the closing circuit to prevent multiple reclosing.
3. When the handcart type circuit breaker fails to reach the test position or working position, the
handcart interlocking board 19 shall buckle the closing board and cut off the closing circuit to prevent the
circuit breaker from entering the load area in the closing state.
4. After the handcart type circuit breaker is closed in the working position or test position, the trolley
will not be able to move if the roller presses the pushing mechanism, so as to prevent pulling out or
pushing the load area in the closing state.
5. If electrical closing locking is selected, manual closing operation is prevented when the secondary
control power supply is not connected.
3.
Technical parameter
3-1 Main technical parameter
No.
Item
Unit
Value
1
Rated voltage
kV
40.5
2
Rated power frequency withstand voltage (1 min)
95/118
Rated lightning impulse withstand voltage
185/215
3
Rated frequency
Hz 50
4
Rated current
A 630/1250/1600/2000/2500/3150
5 Rated short circuit duration s 4
6
Rated short-circuit breaking current
kA
25 31.5
7
Rated short-time withstand current
25 31.5
8
Rated short-circuit making current
kA 63 80
9 Rated peak withstand current kA 63 80
10
Rated operation procedure
O-0.3s-CO-180s-CO
11
Opening/closing rating voltage
V AC: 110/220; DC: 110/220
12
Rated voltage of energy storage motor
V AC: 110/220; DC: 110/220
13
Classification
class E2-M2-C2
