30-0309 - BOOST/FUEL PRESSURE 15PSI SAE ONLY
Specifications
Dimensions
diameter (bezel)
2.40 / 61
in / mm
diameter (cup)
2-1/16 / 52
in / mm
depth (incl. bezel)
0.825 / 21
in / mm
depth (cup only)
0.200 / 5
in / mm
Sensor Installation
past finger tight
1.5 - 3.0
turns
use liquid sealant
Supply Voltage
min
7
VDC
max
18
VDC
Supply Current (13.8V)
nominal
50.0
mA
Operating Temperature
min
-4 / -20
degF / degC
max (16V Supply)
185 / 85
degF / degC
Analog Output
resolution
10
bit
update rate
500
hz
CAN 2.0B Output
bit rate
500
kb/sec
format
29
bit ID
transmit rate
20
hz
terminating resistor
none
endianness
big / Motorola
DLC
8
12 Month Limited Warranty
Advanced Engine Management Inc. w arrants to the consumer that all AEM High Performance products w ill be free from defects in material and
w orkmanship for a period of tw elve (12) months from date of the original purchase. Products that fail within this 12-month warranty period w ill be
repaired or replaced at AEMs option, when determined by AEM that the product failed due to defects in material or w orkmanship. This w arranty is
limited to the repair or replacement of the AEM part. In no event shall this w arranty exceed the original purchase price of the AEM part nor shall
AEM be responsible for special, incidental or consequential damages or cost incurred due to the failure of this product. Warranty claims to AEM
must be transportation prepaid and accompanied w ith dated proof of purchase. This w arranty applies only to the original purchaser of product
and is non-transferable. All implied w arranties shall be limited in duration to the said 12-month w arranty period. Improper use or installation,
accident, abuse, unauthorized repairs or alterations voids this w arranty. AEM disclaims any liability for consequential damages due to breach of
any written or implied w arranty on all products manufactured by AEM. Warranty returns w ill only be accepted by AEM w hen accompanied by a
valid Return Merchandise Authorization (RMA) number. Product must be received by AEM within 30 days of the date the RMA is issued.
UEGO oxygen sensors are considered wear items and are not covered under w arranty.
Please note that before AEM can issue an RMA for any electronic product, it is first necessary for the installer or end user to contact the EMS
tech line at 1-800-423-0046 to discuss the problem. Most issues can be resolved over the phone. Under no circumstances should a system be
returned or a RMA requested before the above process transpires.
AEM w ill not be responsible for electronic products that are installed incorrectly, installed in a non-approved application, misused, or tampered
w ith.
Any AEM electronics product can be returned for repair if it is out of the warranty period. There is a minimum charge of $50.00 for inspection and
diagnosis of AEM electronic parts. Parts used in the repair of AEM electronic components w ill be extra. AEM w ill provide an estimate of repairs
and receive w ritten or electronic authorization before repairs are made to the product.
