1. Mechanism of AEOLUS UC-1803 ICU.INCUBATOR
2. Main Technical Indicators
The patented Energy Saving Low Noise Compressor (less than 25 decibels) generates high speed air
jet from filtered clean air (by anti-bacterial cotton), the air stream disperses the medicine solution from
liquid cup into tiny particles and form medicine aerosol. The average size of droplet could reach 2.5μ
m minus which could reach deep respiratory system like alveolus and fine bronchus. The medicine is
nebulized evenly, no diluted needed, so there is no residues left almost and could achieve very high
medicine utilization rate. This device is preciously made medical equipment with very low faulty rate
and very good durability, could serve for 1000 -1500 hours as minimum lifespan.
Operation Instructions:
The nebulizer is easy to operate, please follow the simple steps as follows.
1. Install the nebulizer on the left side of ICU. Insert the power plug into the socket on the ICU.
2. Screw off the cup lid and nozzle; pour medicine liquid into the nebulizer cup.
3. Screw on the cup lid and nozzle, and put the nebulizer back.
4. Insert the nozzle of Nebulizer into the port. Turn on the nebulizer by pressing the switch on the
nebulizer. And then press Nebulize button on control panel of ICU to switch on nebulization, the
medical fog will be sprayed through grid and get into the ICU chamber. There are two stages of
nebulization treatment timing, in which the basic time is 10 minutes. Once the nebulization process
started, it is 10 minutes countdown automatically; pressing the "-" button on the nebulize adjustment
button will turn it into 20 minutes mode, pressing the "+" will turn back to 10 minutes mode. Pressing
Nebulize button again on the main control panel when the nebulizing process is running will switch the
nebulizer off.
Usage Warning:
a) The treatment process should not exceed 20 minutes for every nebulizing, misuse would possibly
cause Pulmonary edema or water poisoning.
b) To prevent superinfection, please pay close attention to the sterilization of nebulizer, ambient air and
all the related equipment, also disinfect animal mouth, nose and throat.
Mechanism of action
Animal respiratory system is an open system, where alveolus is the main air-exchanging place. The
object sprayed out of the nebulizer is mainly the mixture of oxygen and medicine – oxygen-medicine
aerosol. This kind of aerosol could improve oxygen metabolism and anoxic metabolism significantly;
increase the oxygen reserve in organisms. The cavitation effect of compressed air could disperse the
liquid medicine into gas phase and turn the liquid into fog form. The suspended particles will get deep
into animal respiratory system and treat the focus of infection directly. The feature of air compressing
nebulization technique is generating Big Fog Volume Fog with Ultra Small Particle Size (0.5 -5μm); the
even fog could go very deep into dendritic bronchus and the particles could settle down in deep
respiratory system, achieves painless cure effect. It is a good helper to improve curative effect and
accelerate recovery process.
Tips:
a) The smaller the particles are, the better curative effect the nebulization could achieve.
b) Normally the fog with bigger particles generated from traditional ultrasonic nebulizer would be
easier to be observed, as the fog seems to be thicker.
c) The international of human medical nebulizer is the particles in fog need to be smaller than 5μm.
850EA Air Compressor Nebulizer uses high pressure gas jet knockout the medicine solution into tiny
particles and carry them into deep respiratory system. The size of droplet will affect the settlement site
of medical fog.
endric roncus Fine roncus lveolus
Upper espiratory Tract mainly Nose Troat etc
The air circulation system as shown in Figure 5.1.1 is driven by the circulating air of AEOLUS UC-1803
ICU.INCUBATOR (Pet ICU/Young Pet Incubator). After being filtered by the purifier, the air from the
outside enters into the ICU, and "dual duct and double circulation convection heating technology” is
adopted to create an excellent and bacteria-free ICU therapeutic environment and young pet incuba-
tion environment. It provides clean air and proper temperature and humidity.
1) Power supply voltage: 220V ± 10% / 50Hz ± 2%
2) Input power: ≤400VA
3) Ambient temperature: 10°C ~ 35°C
4) Temperature control range
Cabinet temperature: 15°C ~ 38°C (can be up to 39°C by special operations)
5) Temperature fluctuation: ≤0.8°C
6) Average temperature of monitoring chamber: ≤1.0°C
7) Cabinet temperature control accuracy: ≤ ± 0.5°C
8) Temperature rise time: 5min ~ 20min
9) Noises in monitoring room: ≤30dB
10) Whole machine earth leakage current: ≤0.5 mA (normal state) ≤1 mA (single fault state)
11) Withstand voltage: 1500V/50Hz, lasted one minute without breakdown and flashover.
12) Ambient conditions:
① Transportation and storage:
a. Ambient temperature: -10°C~ 40°C
b. Relative humidity: ≤95%
② Operating conditions:
a. Ambient temperature: 18°C ~ 30°C
b. Relative humidity: 40% ~ 65%
Tips:
a) There is hissing noise when nebulization starts, that’s generated from the high speed air flow. The
patented low noise air compressing technology ensures no vibration and no electronic noise when
nebulizer runs. The noise is much lower than normal level of most air compressor nebulizer, which is
around 85 decibels normally.
b) When nebulization is ON, the ventilation fans will be turned off to ensure good nebulizing effects,
and humidity and temperature control will be turned off too. The humidity alarm will Not be triggered in
nebulization mode, which will reset in 3 minutes after nebulization function turned off.
Figure 5.1.1
04 05
Product Principles and Functions
