5. TECHNICAL DATA
Inputs: Ch1: Line: unbalanced., 2.2 MEG
High/Low: -10 dbV
Ch2: Line: unbalanced., 1MEG
Mic: balanced., 600 Ohm
Eff.Return: -10dBV/10k
Outputs: Tuner: -10dBV
Line: 0dBV
DI: -20dBV
Send: -10dbV
Foot switch Tip: built in effect
Ring: external effect
Sleeve: ground
EQ: Ch1: Bass: +- 18 dB/ 100 Hz
Middle: +- 13 dB/ 550 Hz
Treble: +- 11 dB/ 10 kHz
Ch2: Bass: +- 18 dB/ 100 Hz
Treble: +- 11 dB/ 10 kHz
Analog Signal Processor: Limiter, Subsonic Filter and Enhancer
Effect: Digital Reverb / Delay, two presets
Power Amp: Powerconsumption: 220-240 V / 50-60Hz / 70 VA
(110V / 50-60Hz)
Rating: 60 Watt / 4 ohm rms
Mains Fuse: 1 A slow
Speaker: 8’ twin-cone speaker-system
( 96 dB 1w/1m, freq. range 60Hz-18kHz )
Cabinet: 0.59’ 3(15 mm) birch plywood
Dimension: 10.24’ 3(260 mm) high
13.00’ 3(330 mm) wide
19.06’ 3(230 mm) deep
Finish: waterbased acrylic, black spatter finish
Weight: 18.74 (8.5 kg)
➧ 0dB/V ~ 1V
➧ specifications and appearance subject to change without notice
