3.2 Rear side
1) aux in: stereo input for additional signal sour-
ces, e.g. CD-player, Cinch/RCA-sockets (white =
left channel, red = right channel)
2) line out: The line out supplies a pre-amp signal
taken after tone-control, e ects and master for
forwarding to other appliances.
3) headphones: This output enables you to
connect stereo headphones and mutes the
loudspeaker.
!!!
Warning: Only use headphones
with stereo jackplugs in this output
socket!!!
4) send: Send is an output to connect to an exter-
nal e ect device and in conjunction with return
(input) forms a loop here designed as external
e ect loop. The e ect can be switched on or o
via footswitch.
5) return: Return as part of the e ect loop
operates as signal input from an external e ect
device (from output of the e ect device). The
e ect can be switched on or o via footswitch.
Return on its own can also be used as quasi
auxiliary signal input (-10 dbV).
6) tuner: The tuner output supplies a pre-master
signal (-9 dbV) to connect an external tuner to
the Compact Mobile 2.
7) footswitch: Connection socket for a double-
footswitch (on-/o -switch, tip = internal e ect/
ring = external e ect on/o ).
8) DI-out: Preamp-output with symmetrical
signal, after tone-control, pre master, without
e ects.
9) 12V DC only: Connection socket for an optional
12V-cable to an external battery.
10) DC on/o : On/o -switch for the connection
socket (9).
11) power on: Combined mains switch with mains
socket and fuse holder.
