AER Compact Slope - Technical Specifications Summary

9
6. Technical specications Compact Slope
TD20150224
Technical data
Technical dataTechnical data
Technical data
Inputs
InputsInputs
Inputs (notes 1, 2, 4)
channel 1
channel 1channel 1
channel 1 High impedance, unbalanced input for
instruments (pick-ups) and line-level sources
Mono jack socket, ¼” (6.35 mm)
Sensitivity: 22 mV (–33 dBV)
High/low (attenuator) switch: –10 dB
Impedance: 2.2 Meg
Equivalent input noise, A-weighted:
1 uV (–120 dBV)
Phantom power (optional): 9 V DC / max. 100 mA,
short-circuit protected
Switchable instrument or microphone input
Combo socket, XLR + jack ¼” (6.35 mm)
line mode
line modeline mode
line mode
High impedance, unbalanced input for
instruments (pick-ups) and line-level sources
Jack socket only
Sensitivity: 27 mV (–31 dBV)
Impedance: 1 Meg
Equivalent input noise, A-weighted:
2.4 uV (–112 dBV)
channel 2
channel 2channel 2
channel 2
mic mode
mic modemic mode
mic mode
XLR (balanced), stereo jack (balanced), or mono
jack (unbalanced) input
Sensitivity: 3.3 mV (–50 dBV)
Impedance (balanced mode): 1.2 k
Impedance (unbalanced mode): 2.7 k
Voice filter: –10 dB at 270 Hz (referred to 10 kHz)
Equivalent input noise, A-weighted:
0.8 uV (–122 dBV)
Phantom power (XLR only): 48 V, max. 10 mA,
short-circuit protected
clip
clip clip
clip indicators
for ch. 1 and 2
Headroom: min. 8 dB
return
returnreturn
return Input from external parallel effect loop, or
supplementary input, before master volume
Mono jack, ¼” (6.35 mm)
Sensitivity: 320 mV (–10 dBV)
Impedance: 20 k (note: impedance changes to 5 k
while external effect is switched OFF by
footswitch)
Outputs
OutputsOutputs
Outputs (note 3)
phones
phonesphones
phones Headphones output. When plugged in, internal
speaker is muted.
Stereo jack socket, L/R connected, ¼” (6.35 mm)
Max. output power: 2 x 100 mW / 1000 ohm
Input sensitivity for 2 x 50 mW / 1000 ohm:
23 mV (–33 dBV) at channel 1 input
Impedance: 470 ohm (common for L and R)
Note:
Note: Note:
Note: Suitable for headphones with stereo jack.
Does not work with mono jacks.
tuner
tunertuner
tuner Tuner output
Mono jack socket ¼” (6.35 mm)
Output voltage: 340 mV (–9 dBV)
line out
line outline out
line out Preamplifier output after tone controls, with
effects, and after master volume
Mono jack, ¼” (6.35 mm)
Output voltage: 1.4 V (+3 dBV)
DI
DIDI
DI-
--
-out
outout
out Balanced XLR output before master, after tone
controls, without effects
1 = ground
2 = positive
3 = negative
Differential output voltage: 140 mV (–17 dBV)
send
sendsend
send Output to external parallel effect loop
Before master, after tone controls
Mono jack, ¼” (6.35 mm)
Output voltage: 1.4 V (+3 dBV)
Footswitch connector
Footswitch connectorFootswitch connector
Footswitch connector
footswitch
footswitchfootswitch
footswitch Stereo jack socket ¼” (6.35 mm) for a dual
footswitch
Tip = internal effect on/off
Ring = external effect on/off
Sleeve = common (ground)
Effect is OFF when the footswitch is ON.
Tone controls
Tone controlsTone controls
Tone controls
ch. 1
ch. 1ch. 1
ch. 1 colour
colourcolour
colour –3 dB at 700 Hz, +10 dB at 8 kHz
bass
bassbass
bass ±8 dB at 100 Hz (shelf type)
middle
middlemiddle
middle ±6 dB at 800 Hz
treble
trebletreble
treble ±8 dB at 10 kHz (shelf type)
ch. 2
ch. 2ch. 2
ch. 2
bass
bassbass
bass ±8 dB at 100 Hz (shelf type)
treble
trebletreble
treble ±11 dB at 10 kHz (shelf type)
Effects
EffectsEffects
Effects
Internal effects
Internal effectsInternal effects
Internal effects 1 Reverb 1
2 Reverb 2
3 Delay
4 Chorus
External effect
External effectExternal effect
External effect Parallel effect loop (see also send
sendsend
send and return
returnreturn
return).
eff.
eff.eff.
eff. pan
pan pan
pan Blends both internal and external effects
between channels 1 and 2, with reverse direction
of rotation for the external effects.
Power
PowerPower
Power
Power amp
Power ampPower amp
Power amp 60 W / 4 ohm, DMOS, monolithic I.C.
Dynamic range, A-weighted: 92 dB (note 2)
Limiter
Limiter Limiter
Limiter
threshold
thresholdthreshold
threshold
50 W
Analog signal
Analog signal Analog signal
Analog signal
processing
processingprocessing
processing
Dedicated equalizer, subsonic filter, adaptive
peak limiter
Speaker system
Speaker systemSpeaker system
Speaker system 8” (200 mm) twin cone full-range speaker, bass
reflex enclosure
Mains power
Mains powerMains power
Mains power Mains voltage (depending on model):
100, 120, 230, or 240 V AC, 50–60 Hz
Power consumption: max. 120 W
Mains fuse
Mains fuseMains fuse
Mains fuse 5 x 20 mm
T 1 A L / 250 V for 230 and 240 V models
T 2 A L / 250 V for 100 and 120 V models
General
GeneralGeneral
General
Cabinet
CabinetCabinet
Cabinet 12 mm (0.47”) birch plywood
Finish
FinishFinish
Finish Waterbased acrylic, black spatter finish (standard
model)
Dimensions
DimensionsDimensions
Dimensions 259 mm (10.19“) high
331 mm (13.03“) wide
137 / 326 mm (5.39“ / 12.84”) deep
Weight
WeightWeight
Weight 7.2 kg (15.87 lbs)
Notes:
Notes:Notes:
Notes:
1. Sensitivity
1. Sensitivity1. Sensitivity
1. Sensitivity
Input sensitivities refer to 50 W into 4 ohm, full gain and master settings,
neutral tone control settings, and 1 kHz sine-wave test signal.
2. Noise and dynamic range
2. Noise and dynamic range2. Noise and dynamic range
2. Noise and dynamic range
Equivalent input noise voltages are typical values obtained by measuring
noise voltage at speaker output and dividing by the voltage gain of the
amplifier for white noise. Full gain and master settings, neutral tone
control settings, input shorted, measuring bandwidth 20 Hz – 20 kHz.
Dynamic range of power amplifier: Ratio of between output signal at
limiter threshold to A-weighted output noise with master
mastermaster
master in zero
position.
3. Output levels
3. Output levels3. Output levels
3. Output levels
Output levels refer to 50 mV / 1 kHz sine-wave test signal at channel 1
input, full gain and master settings, neutral tone control settings, send
fully clockwise.
4. Options
4. Options4. Options
4. Options
Gain of channel 2 in mic mode can be decreased by 4.6 dB by an internal
jumper.
48 V phantom power can be deactivated by an internal jumper.
9 V phantom power for channel 1 can be applied by an internal jumper
to the “ring” terminal of the input jack. Caution:
Caution: Caution:
Caution: Use this option with
care. Read the operating instructions.
Specifications and appearance subject to change without notice.
