CONNECT 5/8'' I.D. HOSE TO CONDENSATE DRAIN
SHELL DRAIN VALVE
RELIEF VALVE
SD-A-709
WITH STRATIFIED PEAK STORAGE TANK
KC1000 1 MIL. BTU LOW NOx
6) LOCATE WATER INLET AND OUTLET FITTINGS (i.e. UNIONS, ELBOWS, ETC.) A MINIMUM OF 6'' FROM WATER HEATER FITTINGS TO
3) ALL (*) ITEMS ARE INCLUDED SEPARATELY IN SHIPMENT.
TO A CONVENIENT FLOOR DRAIN. RELIEF VALVE SHOULD BE PIPED VERTICALLY TO A HEIGHT 18'' ABOVE FLOOR.
2) SHELL DRAIN VALVE AND CONDENSATE HOSE SHOULD BE ARRANGED TO PERMIT THE FLUIDS TO DRAIN FREELY, BY GRAVITY,
NOTES:
DRAIN VALVE
UNION
CHECK VALVE
STOP VALVE
5) HOSE CONNECTION AT HEATER OUTLET IS FOR INITIAL HEATER CALIBRATION DURING START-UP.
(NOTE 6)
6''
4) THIS IS A TYPICAL INSTALLATION DRAWING. LOCAL CODES AND AUTHORITIES SHOULD BE CONSULTED.
1) FOR ACTUAL SIZES AND LOCATIONS OF PIPING AND OTHER CONNECTIONS TO THE HEATER, SEE DIMENSIONAL DRAWING.
REMOTE ALARM CONNECTION
7.7" W.C. (PROPANE GAS) AT MAXIMUM BTU/H INPUT
GAS IN - SEE GF-1030 FOR GAS PIPING INSTALLATION
MAINTAIN A REGULATED 8.8" W.C. PRESSURE (NATURAL GAS)/
1-1/4'' MANUAL SHUTOFF *
DIRT TRAP
2'
JK 113006
NTS A
D
LEGEND
TO DRAIN
T
T
SIZE INLET FOR
(NOTE 6)
6''
AT REQUIRED TEMP. RISE
SET AT FLOW
THROTTLING VALVE
T
6''
(NOTE 6)
CONNECTION
HOSE
3:1 PREFERRED
DIA. RATIO: 2:1 MIN.,
TANK HEIGHT TO
HOT WATER OUT
CAPACITY OF HEATER
DIA. = 2/3 TANK DIA.
INLET BAFFLE
FLOW 2 FT
/SEC
PUMP (SEE NOTE 7)
EXPANSION TANK
7) PUMP SHOULD BE CAPABLE OF HEATER'S RATED FLOW AT DESIGN TEMPERATURE RISE.
FOR TWO TEMPERATURE ZONE INSTL.
RELIEF VALVE
THERMOMETER
T
COLD WATER SUPPLY
120°F HOT
WATER OUT
140°F
120°F RECIRC
TEMPERING VALVE
*
*
140°F RECIRC
BALANCING VALVE
APPD.CHKD.
DWN.BY
SIZESCALE
DATE
REV.
NORTHVALE, NJ 07647
INTERNATIONAL, INC.
AERCO
8) MOUNT TEMPERATURE SWITCH 1/3 UP FROM THE BOTTOM OF THE TANK, SWITCH WILL TURN PUMP ON AND OFF.
SWITCH
(NOTE 8)
TEMPERATURE
VACUUM BREAKER
BACKFLOW PREVENTER
(NOTE 12)
BREAKER
VACUUM
(NOTE 10)
12) WHEN REQUIRED BY LOCAL CODES, A VACUUM BREAKER MUST BE INSTALLED WITH THE STORAGE TANK.
10) IF PERMITTED BY LOCAL CODES, A CHECK VALVE MAY BE USED IN PLACE OF A BACKFLOW PREVENTER.
11) CONSULT LOCAL CODES FOR PROPER TYPE OF CONNECTIONS TO STORAGE TANK.
GAS FIRED WATER HEATER
MANDATORY GAS PRESSURE REGULATOR (SUPPLIED BY OTHERS)
(FOR DUAL-FUEL INSTALLATION, SEE NOTE 9)
(FOR DUAL-FUEL INSTALLATION, SEE NOTE 9)
DUAL GAS PIPING SYSTEM TO PREVENT DIRECT FLOW OF FUEL FROM ONE SYSTEM OF GAS PIPING
- INSTALL APPROPRIATE REGULATOR FOR CURRENT FUEL IN USE.
- INSTALLER MUST CHECK WITH LOCAL CODES REGARDING ACCEPTABLE METHOD OF DESIGNING
INTO ANOTHER (FOR EXAMPLE, FROM NATURAL GAS TO PROPANE, AND VICE VERSA).
9) FOR DUAL-FUEL INSTALLATION:
PREVENT INTERFERENCE WITH REMOVAL OF HEATER PANELS. WHEN A FLEX CONNECTOR IS FACTORY SUPPLIED
BY AERCO, IT MUST BE INSTALLED AT THE HOT WATER OUTLET CONNECTION OF THE WATER HEATER.
ALL PIPING & ELECTRIC CONNECTIONS (SERVICE SWITCHES, CONDUIT BOXES) SHOULD BE 6" AWAY FROM SIDE PANELS.
LOCATE GAS PRESSURE REGULATOR A MINIMUM OF 2' FROM HEATER.
