1. MINIMUM CLEARANCES FOR INDOOR UNIT
CHOOSING THE INSTALLATION AREA FOR THE
INDOOR UNIT
• There must be no obstacles near the air discharge
outlets and air suction inlets of the indoor unit, so
that the air can circulate freely.
• Ensure the installation complies with the minimum
technical clearances.
• The position where the unit will be located must be
resistant, and capable to support 4 times the weight
of the indoor unit, and must not increase the noise
level or vibrations produced during operation.
• The installed unit must be leveled.
• The site of the installation must allow easy
condensate drainage and easy connection to the
outdoor unit.
• Ensure there is adequate space for care and
maintenance.
• Use the installation jig kit to determine the spots to
be drilled.
• When you install the suspension bars make sure
that the anchor points to the ceiling and the bar
can support at least 4 times the weight of the unit.
If this is not the case, ensure that the location is
strengthened before installing the unit.
• Installation in dusty or smoky environments
(kitchens with cookers, etc.) can clog the heat
exchanger and the condensate discharge pump,
resulting in reduced performance and the risk of
condensate water overflow.
• Install the unit far away from cookers to avoid the
intake of fumes into the air conditioner.
• Install the unit further than 1m away from other
electrical appliances such as TVs, radios, audio
equipment, etc.
• Do not install the unit in a location where it could be
affected by inflammable gas leaks.
• Do not install the unit near a laundry, bathroom,
shower or swimming pool.
• To avoid problems with the air conditioner, avoid
installation in locations:
• Where there is a lot of oil.
• Where there is an acid base.
• Where the power supply is irregular.
23
13. MINIMUM CLEARANCES FOR INDOOR UNIT
70mm
50mm
50mm
1500mm
