AERMEC CWX250W - Dimensions [MM]

16
DIMENSIONS [mm]
A
B
C
A B C
CWX_W222V
CWX_W223V
CWX_W22VL
880 298 205
CWX_W322V
CWX_W323V
CWX_W32VL
990 305 210
CWX_W422V
CWX_W423V
CWX_W42VL
1170 360 220
CWX_W A B C D E F G H I J
222V - 223V - 22VL 880 298 190 90 68 21 36 25 40 Ø70
322V - 323V - 32VL 990 305 191 91 69 24 46 28 50 Ø70
422V - 423V - 42VL 1170 360 139 210 115 21 42 25 46 Ø70
1500
mm
150
mm
150
mm
150mm
1900 - 2200
mm
I
J
J
J
J
I
FCW 22
FCW 32
FCW 42
