AERMEC CWX250W - Wiring Diagram Cwx500 W - Cwx700 W

22
WIRING DIAGRAM
(COOL ONLY)
AUX. AUXILIARY SWITCH
:
FOR MODEL: CWX500W & CWX700W
LEGEND:
ID
IFM
C A P.
INDOOR FAN
INDOOR COIL
FAN CAPACITOR
:
:
:
TB
SM
RM
TERMINAL BLOCK
ROOM SENSOR
STEP MOTOR
:
:
:
GROUND
LINE
N NEUTRAL
:
:
:
L
THERMISTOR
MOTOR
HI MED LOW COM
L
C
P15 P11 P9
P21
P18
P17
P19
P2
P1
P20
P22
SM
ID
P6
IFM
RD
BR
C A P.
DB DISPLAY BOARD
:
DB
RM
WIR
AUX.
WIR WIRED REMOTE UNIT
:
(OPTIONAL)
RD
TB
L N 1 2 3
YL/GR
MODEL: CWX500W
IFM WIRED TO - HI(GR), MED(YL) & LOW(BL)
IFM
INDOOR FAN MOTOR CON:
(GR)
(YL)
(BK)
(BL)
SPEED 3
SPEED 2
SPEED 4
SPEED 1
MODEL: CWX700W
IFM WIRED TO - HI(BK), MED(GR) & LOW(YL)
(WH)
(RD)
COMMON
COMMON
(BR) CAPACITOR
COLOR CODE:
BLACK
BLUE
:
:
:
:
YL YELLOW
GR GREEN
BK
BL
:
BR BROWN
RD RED
:
INDOOR UNIT
BR
BR
BL
WIRING DIAGRAM CWX500W - CWX700W
