control card input/output
I/O
Type
FCL hydronic cassette
(twin/single)
Electrical characteristics
CN1
Rapido
CN1: connector for 4-LED
receiver (on the unit)
Connector for 4-LED receiver (on the unit)
OO
Faston 6.35mm V0: output not used
Potential-free Faston. Used to support 4-speed
motors.
O1
Faston 6.35mm
V1: minimum fan speed
output
Output: voltage 230V AC, current 5 A (Relay)
O2
Faston 6.35mm V2: medium fan speed output Output: voltage 230V AC, current 5 A (Relay)
O3
Faston 6.35mm
V3: maximum fan speed
output
Output: voltage 230V AC, current 5 A (Relay)
N
Faston 6.35mm N: neutral Output: neutral fan
N
Faston 6.35mm N: neutral Neutral louvre motor
O4
Faston 6.35mm
Y2: water valve output 2
(FCL 4 pipes)
Output: voltage 230V AC, current 5 A (Relay)
O5
Faston 6.35mm
MA: continuous louvre motor
output
Output: voltage 230V AC, current 5 A (Relay)
O6
Faston 6.35mm
Y1: water valve output 1 in
FCL
Output: voltage 230V AC, current 5 A (Relay)
O7_2
Faston 6.35mm Output: voltage 230V AC, current 10 A (Relay) (**)
O7_1
Faston 6.35mm Input: voltage 230V AC, current 10 A (Relay) (**)
O8
Faston 6.35mm on
the relay
RE:heater accessory output Output: voltage 230V AC, current 30 A (Relay)
L
Faston 6.35mm on
the relay
L: line Power supply line input 230V AC
N
Faston 6.35mm N: neutral Power supply neutral input 230V AC
CN2
S1
Rapido Molex SA: ambient probe input NTC 10Kohm
CN3
S2
Rapido Molex SW: Water probe NTC 10Kohm
m2
S3
2 Minifaston 2.8mm
SR2: heater probe on the
second heater (twin)
NTC 10Kohm
m2
S4
2 Minifaston 2.8mm
SR: heater probe (NTC
heater)
NTC
C1
2 Faston 6.35mm
CE: ext. contact (can be used
as remote on/off or alarm)
Optoinsulated input (for clean contact)
C2
2 Minifaston 2.8mm AL1 Digital alarm input (for clean contact)
SW1-
SW2
SW1-2 16 dip switch
CN4
Rapido Molex Not used
J1
Strip step 2.54mm MCU programming Various programming and control signals
(**) Clean contact
