WARNING:
appropriate personal protection.
WARNING:
operations on the unit.
WARNING:
correct operation.
In the specific case of electrical connec
insulation resistance.
If the fan coil unit operates continuously
in cooling mode in a room with high rela-
tive humidity, condensate might form on
the air discharge. This condensate might
be deposited on the floor and on any
objects underneath. To prevent the for-
mation of condensation on the exterior
of the unit while the fan is operating, the
average water temperature should not
drop below the operating limits shown
in the manual determined by the room
temperature and humidity conditions.
These limits refer to unit operation with
fan at minimum speed.
In order to avoid air stratification and
therefore achieve better mixing it is
advised not supply the fan coil unit with
water hotter than 65°C. The use of very
hot water could cause creaking due to
the thermal expansion of the different
components (plastics and metals). This
does not cause damage to the unit if the
A
B
C
I
J
J
J
J
I
FCW 22
FCW 32
FCW 42
J
J
I
FCW 52
FCW A B C D E F G H I J
880 298 190 90 68 21 36 25 40 Ø70
990 305 191 91 69 24 46 28 50 Ø70
1170 360 139 210 115 21 42 25 46 Ø70
1451 365 149 200 114 30 46 34 50 Ø70
1500
mm
150
mm
150
mm
150mm1900 - 2200 mm
A B C
880 298 205
990 305 210
1170 360 220
1450 356 230
