23
IVEDPY 1110 - 4879010_01
COOLING CAPACITY - VED640 / VED641
Tw [°C] DT [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
5
3
15 13214 9764 13155 11109 13214 12461 13626 13626 14910 14910 15559 15559
17 17050 9714 17015 11085 16981 12437 16947 13784 16895 15119 16913 15791
19 21195 9635 21144 11009 21093 12372 21041 13725 20990 15057 20956 15725
21 25581 10906 25513 12271 25444 13622 25376 14970 25358 15645
23 30275 12134 30241 13515 30138 14857 30104 15533
5
15 11400 8874 11660 10318 12154 11776 13002 13002 14310 14310 14957 14957
17 15456 8953 15422 10319 15371 11664 15439 13044 15611 14418 15782 15119
19 19654 8911 19619 10289 19585 11654 19551 13013 19517 14350 19448 15004
21 24108 10219 24039 11582 24005 12945 23954 14297 23937 14971
23 28870 11485 28802 12844 28733 14199 28699 14873
7
15 9139 7730 9987 9352 10918 10889 12178 12178 13544 13544 14227 14227
17 13144 7893 13120 9252 13332 10676 13756 12162 14321 13646 14698 14397
19 17803 8074 17769 9445 17735 10804 17666 12141 17701 13503 17735 14192
21 22395 9449 22326 10805 22292 12163 22258 13519 22223 14180
23 27226 10751 27192 12123 27123 13474 27089 14145
7
3
15 10258 8338 10399 9715 10965 10965 12272 12272 13568 13568 14204 14204
17 14121 8336 14086 9695 14039 11038 14027 12382 14274 13772 14463 14431
19 18249 8276 18215 9649 18180 11009 18112 12340 18095 13683 18043 14335
21 22635 9561 22566 10917 18112 12340 22463 13613 22446 14285
23 27329 10806 27294 12177 27226 13528 27192 14198
5
15 8468 7428 9210 8964 10282 10282 11636 11636 12967 12967 13615 13615
17 12272 7504 12225 8850 12390 10252 12743 11696 13285 13125 13732 13732
19 16553 7526 16519 8893 16501 10254
16450 11590
16433 12931 16467 13622
21 21024 8855 20990 10224 20956 11577 20887 12910 20870 13578
23 25787 10134 25752 11500 25684 12847 25650 13516
7
15 6595 6322 7938 7938 9375 9375 10800 10800 12178 12178 12861 12861
17 9257 6194 9799 7735 10505 9299 11318 10850 12272 12272 12884 12884
19 14227 6537 14227 7911 14180 9248 14321 10654 14651 12101 14840 12828
21 19071 8029 19037 9389 19003 10735 18968 12078 18968 12753
23 23971 9374 23937 10734 23868 12074 23868 12756
9
3
15 7467 6969 8279 8279 9604 9604 10918 10918 12213 12213 12861 12861
17 10976 6936 10929 8275 11035 9651 11377 11052 12248 12248 12884 12884
19 15131 6919 15097 8280 15062 9627 15016 10958 14981 12291 15005 12972
21 19499 8212 19448 9565 19414 10913 19380 12258 19345 12911
23 24211 9480 24159 10833 24108 12180 24074 12846
5
15 6136 6087 7490 7490 8892 8892 10270 10270 11612 11612 12272 12272
17 8621 5929 8998 7393 9610 8900 10446 10395 11636 11636 12296 12296
19 13167 6103 13144 7458 13120 8805 13191 10177 13450 11585 13638 12302
21 17701 7470 17666 8826 17632 10166 17598 11504 17581 12165
23 22497 8779 22463 10133 22395 11470 22395 12150
7
15 4640 4640 6395 6395 7938 7938 9398 9398 10812 10812 11495 11495
17 5582 4564 6925 6326 8173 7993 9422 9422 10835 10835 11518 11518
19 10034 4858 10105 6232 10505 7704 11118 9238 11848 10768 12248 11543
21 15371 6547 15336 7892 15336 9239 15371 10597 15473 11304
23 20442 7971 20407 9319 20373 10663 20339 11321
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensible cooling capacity
NB: The values in bold type indicate the rated value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
VED 640/641
Qv [m
3
/h] k (Pc) k (Ps)
Rated speed 2450 1 1
Maximum speed 2200 0.92 0.92
Average speed 1770 0.78 0.77
Minimum speed 1370 0.63 0.62
COOLING CAPACITY CORRECTION FACTORS
