AERMEC VED - Technical Data

12
IVEDPY 1902 - 4460510_00
TECHNICAL DATA
Mod. VED Speed. 30 40 130 140 230 240 330 340
2-PIPE SYSTEM CONFIGURATION
Thermal power (70°C)
(1) W H 3688 3916 6289 6575 7160 7909 10507 10951
(1) W M 3374 3568 5833 6089 6500 7141 9343 10017
(1) W L 1820 2366 4397 4518 5350 5800 7813 8312
Water ow rate
(1) l/h H 323 343 551 576 616 684 921 960
(1) l/h M 296 313 511 534 559 616 819 878
(1) l/h L 160 207 385 396 460 499 685 72
Pressure drops
(1) kPa H 9 12 26 18 37 3 16 32
(1) kPa M 7 10 22 16 30 26 13 28
(1) kPa L 3 4 13 9 27 18 9 22
Thermal power (50°C)
(2) W H 2180 2340 3750 3940 4320 4750 6270 6550
(2) W M 1990 2130 3480 3650 3920 4290 5580 5980
(2) W L 1100 1410 2620 2710 3230 3450 4670 4970
Water ow rate
(2) l/h H 279 327 516 566 588 691 860 922
(2) l/h M 250 296 480 525 538 624 760 824
(2) l/h L 170 193 358 390 445 499 633 685
Pressure drops
(2) kPa H 8 12 27 19 35 31 16 21
(2) kPa M 7 10 23 16 29 26 13 17
(2) kPa L 3 5 13 9 20 13 9 13
4-PIPE SYSTEM CONFIGURATION (with additional heat exchanger)
Thermal power (70°C)
(3) W H 2220 - 3780 - 4493 - 5888 -
(3) W M 2080 - 3596 - 4171 - 5499 -
(3) W L 1590 - 2946 - 3675 - 4896 -
Water ow rate
(3) l/h H 196 - 331 - 394 - 515 -
(3) l/h M 183 - 315 - 366 - 482 -
(3) l/h L 140 - 258 - 322 - 429 -
Pressure drops
(3) kPa H 8 - 28 - 16 - 26 -
(3) kPa M 7 - 25 - 14 - 23 -
(3) kPa L 5 - 17 - 11 - 19 -
COLD OPERATION common to all system congurations
Total cooling capacity
(4) W H 1624 1900 2997 3290 3420 4020 5000 5360
(4) W M 1454 1720 2790 3050 3130 3630 4420 4790
(4) W L 990 1120 2080 2270 2590 2900 3680 3980
Sensitive cooling capacity
(4) W H 1242 1350 2090 2370 2700 3015 3738 3990
(4) W M 1116 1230 1940 2190 2440 2718 3337,5 3570
(4) W L 750 810 1440 1610 2000 2200 2800 2950
Water ow rate
(4) l/h H 279 327 515 566 588 691 860 922
(4) l/h M 250 296 480 525 538 624 760 824
(4) l/h L 170 193 358 390 445 499 633 685
Water pressure drops
(4) kPa H 9 14 31 23 44 37 18 26
(4) kPa M 7 12 27 20 36 31 14 21
(4) kPa L 3 5 15 11 25 16 10 16
Air ow rate
m
3
/h H 285 277 433 420 590 570 805 775
m
3
/h M 256 249 397 386 524 509 704 685
m
3
/h L 161 160 287 280 417 406 572 563
Fans
tipo centrifugal
n° 1 1 2 2 2 2 3 3
Input power
Pa H 61 61 60 60 64 63 66 64
Pa M 50 50 50 50 50 50 50 50
Pa L 21 21 26 26 32 32 33 34
Potenza assorbita
W H 59 58 76 75 93 92 104 103
W M 38 38 53 52 57 57 75 74
W L 23 23 34 34 43 43 63 63
Maximum input current (A) 0,37 0,37 0,41 0,41 0,58 0,58 0,66 0,66
Sound power (inlet+radiator)
(5) dB(A) H 54 54 55 55 57 57 58 58
(5) dB(A) M 52 52 53 53 54 54 55 55
(5) dB(A) L 39 39 45 45 44 44 38 38
Sound power (outlet)
(5) dB(A) H 50 50 50 50 42 42 54 54
(5) dB(A) M 48 48 48 48 49 49 51 51
(5) dB(A) L 34 34 39 39 39 39 34 34
Coil connections ø Gas (F) 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Coil connections (additional heat
exchanger)
ø Gas (F) 1/2" - 1/2" - 1/2" - 1/2" -
0-10V signal
H V6 V6 V6 V6 V6 V6 V7 V7
M V4 V4 V4 V4 V3 V3 V3 V3
L V1 V1 V1 V1 V1 V1 V1 V1
Electric power supply 230V/1/50Hz
H maximum speed; M medium speed; L minimum speed
Heating
2-pipe system configuration
(1) Ambient air temperature 20°C d.b.; Inlet water temperature 70°C; DT water
10°C
2-pipe system configuration (EUROVENT)
(2) Ambient air temperature 20°C d.b.; Inlet water temperature 50°C; Water
flow rate
the same as in Cooling mode
4-pipe system configuration with additional heat exchanger
(3) Ambient air temperature 20°C d.b.; Inlet water temperature 70°C; DT water
10°C
Cooling (EUROVENT)
(4) Ambient air temperature 27°C d.b./19°C w.b.; Inlet water temperature 7°C;
DT water
5°C
(5) Sound power based on the measurements carried out in accordance with
Eurovent
8/2 standard
Note: For further information, refer to the selection program or to the
technical
documentation on www.aermec.com
