AERMEC VED - Page 69

12
IVEDPY 2005 - 4879010_04
COOLING CAPACITY - VED430
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensible cooling capacity
NB: The values in bold type indicate the rated value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
VED 430
Qv [m
3
/h] k (Pc) k (Ps)
Maximum Rated speed V5 1520 1 1
Maximum speed 1350 0.87 0.86
Average speed 1130 0.77 0.76
Minimum speed 790 0.58 0.57
Tw [°C] DT [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
5
3
15 6434 5244 6406 5966 6434 6434 6635 6635 7260 7260 7576 7576
17 8302 5217 8285 5954 8269 6680 8252 7403 8227 8120 8235 8235
19 10321 5175 10296 5913 10271 6645 10246 7371 10221 8086 10204 8445
21 12456 5857 12423 6591 12390 7316 12356 8040 12348 8402
23 14742 6517 14725 7259 14675 7979 14659 8342
5
15 5551 4766 5677 5541 5918 5918 6331 6331 6968 6968 7283 7283
17 7526 4808 7509 5542 7484 6265 7518 7005 7601 7601 7685 7685
19 9570 4786 9553 5526 9537 6259 9520 6989 9503 7707 9470 8058
21 11739 5488 11705 6220 11689 6952 11664 7679 11655 8040
23 14058 6168 14025 6898 13991 7626 13974 7988
7
15 4450 4152 4863 4863 5316 5316 5930 5930 6595 6595 6928 6928
17 6400 4239 6389 4969 6492 5734 6698 6532 6974 6974 7157 7157
19 8669 4337 8652 5073 8636 5802 8602 6520 8619 7252 8636 7622
21 10905 5075 10871 5803 10855 6532 10838 7261 10821 7616
23 13257 5774 13240 6511 13207 7236 13190 7597
7
3
15 4995 4478 5064 5064 5339 5339 5976 5976 6606 6606 6916 6916
17 6876 4477 6859 5207 6836 5928 6830 6650 6951 6951 7042 7042
19 8886 4445 8869 5182 8853 5913 8819 6627 8811 7349 8786 7699
21 11021 5135 10988 5863 8819 6627 10938 7311 10930 7672
23 13307 5804 13290 6540 13257 7265 13240 7625
5
15 4123 3989 4484 4484 5006 5006 5666 5666 6314 6314 6629 6629
17 5976 4030 5953 4753 6033 5506 6205 6205 6469 6469 6687 6687
19 8060 4042 8043 4776 8035 5507
8010 6225
8002 6945 8018 7316
21 10237 4756 10221 5491 10204 6217 10171 6933 10162 7292
23 12556 5443 12540 6176 12506 6900 12490 7259
7
15 3211 3211 3865 3865 4565 4565 5259 5259 5930 5930 6262 6262
17 4507 3327 4771 4154 5115 4994 5511 5511 5976 5976 6274 6274
19 6928 3511 6928 4249 6905 4967 6974 5722 7134 6499 7226 6889
21 9286 4312 9270 5043 9253 5765 9236 6487 9236 6849
23 11672 5034 11655 5765 11622 6484 11622 6851
9
3
15 3636 3636 4031 4031 4677 4677 5316 5316 5947 5947 6262 6262
17 5345 3725 5322 4444 5373 5183 5540 5540 5964 5964 6274 6274
19 7368 3716 7351 4447 7334 5170 7312 5885 7295 6601 7306 6967
21 9495 4410 9470 5137 9453 5861 9436 6583 9420 6934
23 11789 5091 11764 5818 11739 6542 11722 6899
5
15 2988 2988 3647 3647 4330 4330 5001 5001 5654 5654 5976 5976
17 4198 3184 4381 3971 4679 4679 5087 5087 5666 5666 5987 5987
19 6411 3278 6400 4005 6389 4729 6423 5466 6549 6222 6641 6607
21 8619 4012 8602 4740 8586 5460 8569 6179 8561 6533
23 10955 4715 10938 5442 10905 6160 10905 6525
7
15 2259 2259 3114 3114 3865 3865 4576 4576 5264 5264 5597 5597
17 2718 2451 3372 3372 3980 3980 4588 4588 5276 5276 5609 5609
19 4886 2609 4920 3347 5115 4138 5414 4961 5769 5769 5964 5964
21 7484 3516 7468 4238 7468 4962 7484 5691 7535 6071
23 9954 4281 9937 5005 9920 5726 9904 6080
COOLING CAPACITY CORRECTION FACTORS
