Tw [°C] DT [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 2698 2698 3369 3369 4020 4020 4657 4657 5293 5293 5609 5609
17 3681 2946 3813 3708 4100 4100 4668 4668 5305 5305 5620 5620
19 5723 2971 5712 3696 5700 4412 5706 5138 5827 5827 5895 5895
21 7868 3683 7852 4407 7835 5123 7818 5838 7810 6190
23 10162 4372 10137 5093 10121 5814 10104 6169
5
15 2202 2202 2950 2950 3653 3653 4330 4330 4989 4989 5316 5316
17 2535 2373 3074 3074 3659 3659 4335 4335 5001 5001 5328 5328
19 4519 2453 4530 3179 4668 3944 4926 4741 5264 5264 5454 5454
21 6859 3252 6847 3974 6847 4694 6847 5413 6882 5785
23 9220 3973 9220 4702 9186 5412 9186 5773
7
15 1289 1289 2317 2317 3142 3142 3882 3882 4588 4588 4932 4932
17 1292 1292 2328 2328 3148 3148 3894 3894 4599 4599 4938 4938
19 2133 1464 2948 2468 3561 3387 4129 4129 4685 4685 4972 4972
21 5333 2629 5345 3354 5505 4126 5758 4927 5907 5327
23 8052 3499 8043 4218 8035 4936 8018 5286
13
3
15 2007 2007 2695 2695 3358 3358 4003 4003 4639 4639 4955 4955
17 2168 2168 2701 2701 3366 3366 4008 4008 4651 4651 4966 4966
19 3945 2213 3934 2925 4031 3671 4267 4267 4662 4662 4978 4978
21 6125 2949 6113 3667 6102 4376 6090 5086 6119 5453
23 8419 3647 8410 4369 8385 5079 8377 5433
5
15 1364 1364 2225 2225 2959 2959 3653 3653 4324 4324 4657 4657
17 1370 1370 2228 2228 2965 2965 3659 3659 4335 4335 4668 4668
19 2145 1472 2689 2365 3211 3211 3733 3733 4341 4341 4674 4674
21 4886 2453 4886 3171 4989 3914 5207 4696 5333 5086
23 7351 3225 7334 3937 7318 4646 7318 5003
7
15 651 651 1301 1301 2368 2368 3165 3165 3900 3900 4249 4249
17 651 651 1301 1301 2368 2368 3177 3177 3905 3905 4255 4255
19 671 671 1306 1306 2397 2397 3183 3183 3911 3911 4267 4267
21 2477 1531 3177 2471 3762 3364 4301 4236 4553 4553
23 5804 2638 5804 3350 5918 4103 6010 4489
15
3
15 1283 1283 2010 2010 2689 2689 3346 3346 3986 3986 4307 4307
17 1286 1286 2013 2013 2695 2695 3355 3355 3997 3997 4312 4312
19 1875 1366 2268 2185 2741 2741 3360 3360 4003 4003 4324 4324
21 4221 2194 4209 2898 4278 3632 4467 4391 4599 4599
23 6555 2920 6549 3632 6526 4334 6520 4686
5
15 521 521 1410 1410 2239 2239 2965 2965 3653 3653 3991 3991
17 522 522 1410 1410 2242 2242 2970 2970 3659 3659 3997 3997
19 525 525 1422 1422 2248 2248 2976 2976 3670 3670 4003 4003
21 2351 1486 2856 2349 3349 3200 3842 3842 4095 4095
23 5253 2437 5253 3144 5316 3874 5396 4255
7
15 103 103 651 651 1353 1353 2403 2403 3188 3188 3555 3555
17 103 103 651 651 1353 1353 2408 2408 3194 3194 3561 3561
19 103 103 651 651 1358 1358 2414 2414 3200 3200 3567 3567
21 675 675 1399 1399 2483 2483 3229 3229 3578 3578
23 2787 1566 3429 2469 3980 3338 4244 3766
COOLING CAPACITY - VED430
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensible cooling capacity
NB: The values in bold type indicate the rated value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
VED 430
Qv [m
3
/h] k (Pc) k (Ps)
Maximum Rated speed V5 1520 1 1
Maximum speed 1350 0.87 0.86
Average speed 1130 0.77 0.76
Minimum speed 790 0.58 0.57
COOLING CAPACITY CORRECTION FACTORS
