AERMEC VED - Page 71

14
IVEDPY 2005 - 4879010_04
COOLING CAPACITY - VED440 / VED441
Tw [°C] DT [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
5
3
15 7463 5623 7429 6398 7463 7177 7695 7695 8420 8420 8787 8787
17 9629 5594 9609 6384 9590 7163 9571 7938 9542 8707 9551 9094
19 11970 5549 11941 6340 11912 7125 11883 7904 11854 8671 11835 9056
21 14447 6281 14408 7067 14369 7845 14331 8622 14321 9010
23 17098 6988 17078 7784 17020 8556 17001 8946
5
15 6438 5111 6585 5942 6864 6782 7343 7343 8081 8081 8447 8447
17 8729 5156 8710 5943 8680 6718 8719 7512 8816 8304 8913 8707
19 11099 5132 11080 5926 11061 6711 11041 7494 11022 8265 10983 8641
21 13615 5885 13576 6670 13557 7455 13528 8234 13518 8622
23 16304 6614 16266 7397 16227 8178 16208 8565
7
15 5161 4452 5640 5386 6166 6166 6877 6877 7649 7649 8035 8035
17 7423 4546 7409 5329 7529 6149 7769 7004 8088 7859 8301 8292
19 10054 4650 10035 5440 10016 6222 9977 6992 9996 7776 10016 8174
21 12647 5442 12609 6223 12589 7005 12570 7786 12550 8167
23 15376 6192 15356 6982 15317 7760 15298 8146
7
3
15 5793 4802 5873 5595 6192 6192 6931 6931 7662 7662 8021 8021
17 7975 4801 7955 5583 7928 6357 7922 7131 8061 7931 8168 8168
19 10306 4766 10287 5557 10267 6340 10228 7107 10219 7880 10190 8256
21 12783 5506 12744 6288 10228 7107 12686 7840 12676 8227
23 15434 6224 15414 7013 15376 7791 15356 8177
5
15 4782 4278 5201 5162 5806 5806 6571 6571 7323 7323 7689 7689
17 6931 4322 6904 5097 6997 5904 7197 6736 7503 7503 7755 7755
19 9348 4334 9329 5122 9319 5905
9290 6675
9280 7447 9300 7845
21 11873 5100 11854 5888 11835 6667 11796 7435 11786 7820
23 14563 5837 14543 6623 14505 7399 14485 7784
7
15 3724 3641 4483 4483 5294 5294 6099 6099 6877 6877 7263 7263
17 5228 3567 5534 4455 5933 5355 6392 6249 6931 6931 7276 7276
19 8035 3765 8035 4556 8008 5326 8088 6136 8274 6969 8381 7388
21 10770 4624 10751 5407 10732 6182 10712 6956 10712 7344
23 13537 5399 13518 6182 13479 6953 13479 7346
9
3
15 4217 4013 4676 4676 5424 5424 6166 6166 6897 6897 7263 7263
17 6199 3994 6172 4766 6232 5558 6425 6365 6917 6917 7276 7276
19 8545 3985 8526 4769 8506 5544 8480 6311 8460 7078 8474 7471
21 11012 4729 10983 5509 10964 6285 10944 7060 10925 7436
23 13673 5460 13644 6239 13615 7015 13595 7398
5
15 3465 3465 4230 4230 5022 5022 5800 5800 6558 6558 6931 6931
17 4869 3415 5081 4258 5427 5125 5900 5900 6571 6571 6944 6944
19 7436 3515 7423 4295 7409 5071 7449 5861 7596 6672 7702 7085
21 9996 4302 9977 5083 9958 5855 9938 6626 9929 7006
23 12705 5056 12686 5836 12647 6606 12647 6997
7
15 2620 2620 3611 3611 4483 4483 5308 5308 6106 6106 6492 6492
17 3152 2629 3911 3643 4616 4603 5321 5321 6119 6119 6505 6505
19 5667 2798 5707 3589 5933 4437 6279 5320 6691 6202 6917 6648
21 8680 3771 8661 4545 8661 5321 8680 6103 8739 6510
23 11544 4591 11525 5367 11506 6141 11486 6520
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensible cooling capacity
NB: The values in bold type indicate the rated value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
VED 440/441
Qv [m
3
/h] k (Pc) k (Ps)
Rated speed 1520 1 1
Maximum speed 1340 0.86 0.86
Average speed 1100 0.76 0.76
Minimum speed 780 0.57 0.57
COOLING CAPACITY CORRECTION FACTORS
