AERMEC VED - Page 72

15
IVEDPY 2005 - 4879010_04
Tw [°C] DT [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 3129 3129 3907 3907 4662 4662 5401 5401 6139 6139 6505 6505
17 4269 3159 4423 3976 4755 4755 5414 5414 6152 6152 6518 6518
19 6638 3186 6625 3963 6611 4731 6618 5509 6758 6308 6837 6705
21 9126 3949 9106 4726 9087 5494 9067 6260 9058 6638
23 11786 4688 11757 5461 11738 6235 11718 6615
5
15 2554 2554 3422 3422 4237 4237 5022 5022 5786 5786 6166 6166
17 2940 2545 3565 3487 4243 4243 5028 5028 5800 5800 6179 6179
19 5241 2631 5254 3409 5414 4230 5713 5085 6106 5943 6325 6325
21 7955 3487 7942 4261 7942 5033 7942 5804 7981 6203
23 10693 4260 10693 5042 10654 5803 10654 6191
7
15 1495 1495 2687 2687 3645 3645 4503 4503 5321 5321 5720 5720
17 1498 1498 2700 2700 3651 3651 4516 4516 5334 5334 5727 5727
19 2474 1570 3419 2647 4130 3632 4789 4582 5434 5434 5767 5767
21 6186 2820 6199 3597 6385 4424 6678 5283 6851 5712
23 9338 3752 9329 4524 9319 5293 9300 5668
13
3
15 2328 2328 3126 3126 3894 3894 4642 4642 5381 5381 5747 5747
17 2514 2363 3132 3132 3904 3904 4649 4649 5394 5394 5760 5760
19 4576 2373 4563 3136 4676 3936 4948 4760 5407 5407 5773 5773
21 7103 3162 7090 3932 7077 4693 7064 5454 7097 5848
23 9764 3911 9754 4685 9725 5446 9716 5826
5
15 1582 1582 2580 2580 3432 3432 4237 4237 5015 5015 5401 5401
17 1589 1589 2584 2584 3438 3438 4243 4243 5028 5028 5414 5414
19 2487 1579 3119 2536 3724 3466 4330 4330 5035 5035 5421 5421
21 5667 2630 5667 3400 5786 4197 6039 5036 6186 5454
23 8526 3458 8506 4222 8487 4982 8487 5365
7
15 755 755 1508 1508 2747 2747 3671 3671 4523 4523 4928 4928
17 755 755 1508 1508 2747 2747 3685 3685 4529 4529 4935 4935
19 779 737 1515 1515 2780 2780 3691 3691 4536 4536 4948 4948
21 2873 1642 3685 2649 4363 3607 4988 4542 5281 4995
23 6731 2829 6731 3593 6864 4400 6970 4814
15
3
15 1488 1488 2331 2331 3119 3119 3881 3881 4622 4622 4995 4995
17 1492 1492 2334 2334 3126 3126 3891 3891 4636 4636 5002 5002
19 2175 1465 2630 2343 3179 3179 3897 3897 4642 4642 5015 5015
21 4895 2353 4882 3108 4962 3895 5181 4708 5334 5117
23 7602 3131 7596 3895 7569 4648 7562 5025
5
15 604 604 1636 1636 2597 2597 3438 3438 4237 4237 4629 4629
17 606 606 1636 1636 2600 2600 3445 3445 4243 4243 4636 4636
19 609 609 1649 1649 2607 2607 3452 3452 4257 4257 4642 4642
21 2727 1594 3312 2519 3884 3431 4456 4324 4749 4749
23 6092 2613 6092 3372 6166 4154 6259 4562
7
15 120 120 755 755 1569 1569 2787 2787 3698 3698 4124 4124
17 120 120 755 755 1569 1569 2793 2793 3705 3705 4130 4130
19 120 120 755 755 1575 1575 2800 2800 3711 3711 4137 4137
21 783 725 1622 1622 2880 2852 3744 3744 4150 4150
23 3232 1680 3977 2647 4616 3580 4922 4039
COOLING CAPACITY - VED440 / VED441
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensible cooling capacity
NB: The values in bold type indicate the rated value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
VED 440/441
Qv [m
3
/h] k (Pc) k (Ps)
Rated speed 1520 1 1
Maximum speed 1340 0.86 0.86
Average speed 1100 0.76 0.76
Minimum speed 780 0.57 0.57
COOLING CAPACITY CORRECTION FACTORS
