AERMEC VED - Page 73

16
IVEDPY 2005 - 4879010_04
COOLING CAPACITY - VED530
Tw [°C] DT [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
5
3
15 6957 5691 6926 6474 6957 6957 7174 7174 7849 7849 8191 8191
17 8976 5661 8958 6461 8940 7249 8922 8033 8894 8812 8904 8904
19 11158 5616 11131 6417 11104 7211 11077 7999 11050 8776 11032 9165
21 13467 6356 13431 7152 13395 7939 13359 8725 13350 9118
23 15938 7072 15920 7877 15866 8659 15848 9053
5
15 6002 5172 6138 6013 6399 6399 6845 6845 7533 7533 7874 7874
17 8137 5218 8119 6014 8092 6798 8128 7602 8218 8218 8308 8308
19 10347 5194 10328 5997 10310 6792 10292 7584 10274 8364 10238 8745
21 12691 5956 12655 6750 12637 7545 12610 8333 12601 8725
23 15199 6694 15163 7486 15127 8276 15108 8668
7
15 4811 4505 5258 5258 5747 5747 6411 6411 7130 7130 7490 7490
17 6919 4600 6907 5393 7019 6223 7242 7089 7539 7539 7738 7738
19 9372 4706 9354 5505 9336 6297 9300 7076 9318 7870 9336 8272
21 11790 5507 11753 6297 11735 7089 11717 7879 11699 8265
23 14333 6266 14315 7065 14279 7853 14261 8244
7
3
15 5400 4860 5475 5475 5772 5772 6461 6461 7143 7143 7477 7477
17 7434 4859 7415 5650 7391 6433 7384 7217 7515 7515 7614 7614
19 9607 4824 9589 5624 9571 6416 9535 7192 9526 7975 9499 8355
21 11916 5572 11880 6363 9535 7192 11826 7934 11817 8326
23 14387 6298 14369 7097 14333 7884 14315 8275
5
15 4458 4329 4848 4848 5413 5413 6126 6126 6826 6826 7167 7167
17 6461 4374 6436 5158 6523 5975 6709 6709 6994 6994 7229 7229
19 8714 4386 8696 5183 8687 5976
8660 6755
8651 7536 8669 7939
21 11068 5161 11050 5959 11032 6747 10996 7524 10987 7914
23 13575 5907 13557 6703 13521 7487 13503 7877
7
15 3472 3472 4179 4179 4935 4935 5685 5685 6411 6411 6771 6771
17 4873 3610 5158 4508 5530 5420 5958 5958 6461 6461 6783 6783
19 7490 3810 7490 4611 7465 5390 7539 6209 7713 7053 7812 7476
21 10040 4680 10022 5472 10004 6257 9986 7039 9986 7433
23 12619 5463 12601 6256 12565 7037 12565 7435
9
3
15 3931 3931 4359 4359 5056 5056 5747 5747 6430 6430 6771 6771
17 5778 4042 5754 4823 5809 5625 5989 5989 6448 6448 6783 6783
19 7966 4033 7948 4826 7929 5611 7905 6387 7887 7163 7899 7561
21 10265 4786 10238 5575 10220 6360 10202 7144 10184 7525
23 12746 5525 12718 6314 12691 7099 12673 7487
5
15 3230 3230 3943 3943 4681 4681 5406 5406 6113 6113 6461 6461
17 4538 3456 4737 4309 5059 5059 5499 5499 6126 6126 6473 6473
19 6932 3557 6919 4347 6907 5132 6944 5931 7081 6752 7180 7170
21 9318 4354 9300 5144 9282 5925 9264 6705 9255 7090
23 11844 5117 11826 5906 11790 6685 11790 7081
7
15 2443 2443 3366 3366 4179 4179 4948 4948 5692 5692 6051 6051
17 2939 2660 3646 3646 4303 4303 4960 4960 5704 5704 6064 6064
19 5282 2832 5320 3632 5530 4490 5853 5384 6237 6237 6448 6448
21 8092 3816 8074 4600 8074 5385 8092 6176 8146 6588
23 10761 4646 10743 5431 10725 6214 10707 6598
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensible cooling capacity
NB: The values in bold type indicate the rated value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
VED 530
Qv [m
3
/h] k (Pc) k (Ps)
Rated speed 1700 1 1
Maximum speed 1520 0.90 0.89
Average speed 1400 0.85 0.85
Minimum speed 1120 0.71 0.70
COOLING CAPACITY CORRECTION FACTORS
