AERMEC VED - Page 74

17
IVEDPY 2005 - 4879010_04
COOLING CAPACITY - VED530
Tw [°C] DT [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 2917 2917 3642 3642 4346 4346 5034 5034 5723 5723 6064 6064
17 3979 3197 4123 4024 4433 4433 5047 5047 5735 5735 6076 6076
19 6188 3224 6175 4011 6163 4788 6169 5576 6299 6299 6374 6374
21 8507 3996 8489 4782 8471 5560 8453 6335 8444 6718
23 10987 4744 10960 5527 10942 6310 10924 6695
5
15 2381 2381 3190 3190 3949 3949 4681 4681 5394 5394 5747 5747
17 2740 2576 3323 3323 3956 3956 4687 4687 5406 5406 5760 5760
19 4886 2662 4898 3450 5047 4280 5326 5146 5692 5692 5896 5896
21 7415 3529 7403 4313 7403 5094 7403 5874 7440 6278
23 9968 4311 9968 5102 9932 5873 9932 6265
7
15 1394 1394 2505 2505 3398 3398 4197 4197 4960 4960 5332 5332
17 1397 1397 2517 2517 3404 3404 4210 4210 4972 4972 5338 5338
19 2306 1588 3187 2679 3850 3676 4464 4464 5065 5065 5375 5375
21 5766 2853 5778 3640 5952 4477 6225 5347 6386 5781
23 8705 3797 8696 4578 8687 5357 8669 5737
13
3
15 2170 2170 2914 2914 3630 3630 4328 4328 5016 5016 5357 5357
17 2343 2343 2920 2920 3639 3639 4334 4334 5028 5028 5369 5369
19 4266 2402 4253 3174 4359 3984 4613 4613 5041 5041 5382 5382
21 6622 3200 6609 3980 6597 4749 6585 5520 6616 5918
23 9102 3958 9093 4741 9066 5512 9057 5896
5
15 1475 1475 2405 2405 3199 3199 3949 3949 4675 4675 5034 5034
17 1481 1481 2409 2409 3205 3205 3956 3956 4687 4687 5047 5047
19 2319 1597 2908 2566 3472 3472 4036 4036 4693 4693 5053 5053
21 5282 2662 5282 3441 5394 4248 5630 5096 5766 5520
23 7948 3499 7929 4273 7911 5041 7911 5429
7
15 704 704 1406 1406 2560 2560 3422 3422 4216 4216 4594 4594
17 704 704 1406 1406 2560 2560 3435 3435 4222 4222 4600 4600
19 726 726 1412 1412 2591 2591 3441 3441 4228 4228 4613 4613
21 2678 1662 3435 2681 4067 3650 4650 4597 4923 4923
23 6275 2863 6275 3636 6399 4453 6498 4872
15
3
15 1387 1387 2173 2173 2908 2908 3618 3618 4309 4309 4656 4656
17 1390 1390 2176 2176 2914 2914 3627 3627 4321 4321 4662 4662
19 2027 1482 2452 2371 2963 2963 3633 3633 4328 4328 4675 4675
21 4563 2381 4551 3145 4625 3942 4830 4765 4972 4972
23 7087 3169 7081 3942 7056 4704 7050 5086
5
15 563 563 1525 1525 2421 2421 3205 3205 3949 3949 4315 4315
17 565 565 1525 1525 2424 2424 3211 3211 3956 3956 4321 4321
19 568 568 1537 1537 2430 2430 3218 3218 3968 3968 4328 4328
21 2542 1613 3087 2549 3621 3473 4154 4154 4427 4427
23 5679 2645 5679 3412 5747 4204 5834 4617
7
15 112 112 704 704 1462 1462 2598 2598 3447 3447 3844 3844
17 112 112 704 704 1462 1462 2604 2604 3453 3453 3850 3850
19 112 112 704 704 1469 1469 2610 2610 3460 3460 3856 3856
21 730 730 1512 1512 2684 2684 3491 3491 3869 3869
23 3013 1700 3708 2679 4303 3623 4588 4087
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensible cooling capacity
NB: The values in bold type indicate the rated value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
VED 530
Qv [m
3
/h] k (Pc) k (Ps)
Rated speed 1700 1 1
Maximum speed 1520 0.90 0.89
Average speed 1400 0.85 0.85
Minimum speed 1120 0.71 0.70
COOLING CAPACITY CORRECTION FACTORS
