COOLING CAPACITY - VED540 / VED541
Tw [°C] DT [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
5
3
15 8258 6112 8221 6954 8258 7800 8516 8516 9318 9318 9723 9723
17 10655 6080 10633 6939 10612 7785 10590 8628 10558 9464 10569 9885
19 13246 6031 13213 6891 13181 7745 13149 8591 13117 9425 13096 9844
21 15986 6827 15943 7682 15901 8527 15858 9371 15847 9793
23 18920 7595 18898 8460 18834 9300 18813 9723
5
15 7124 5555 7286 6459 7595 7371 8125 8125 8942 8942 9347 9347
17 9659 5604 9638 6459 9606 7302 9648 8165 9755 9025 9862 9464
19 12282 5578 12261 6441 12239 7295 12218 8146 12196 8983 12154 9392
21 15066 6397 15023 7250 15001 8103 14969 8950 14959 9371
23 18042 7189 17999 8040 17956 8888 17935 9310
7
15 5711 4839 6241 5854 6823 6816 7610 7610 8464 8464 8891 8891
17 8214 4941 8199 5792 8332 6683 8596 7613 8950 8542 9185 9012
19 11126 5054 11104 5912 11083 6763 11040 7600 11062 8452 11083 8884
21 13995 5915 13952 6764 13931 7614 13909 8463 13888 8876
23 17014 6730 16993 7588 16950 8434 16928 8854
7
3
15 6410 5219 6499 6081 6852 6852 7669 7669 8479 8479 8876 8876
17 8825 5218 8803 6069 8773 6910 8766 7751 8920 8621 9038 9033
19 11404 5181 11383 6040 11361 6891 11318 7725 11308 8565 11276 8973
21 14145 5985 14102 6834 11318 7725 14038 8521 14027 8942
23 17078 6764 17057 7622 17014 8468 16993 8888
5
15 5292 4650 5755 5611 6425 6425 7272 7272 8103 8103 8508 8508
17 7669 4697 7640 5540 7743 6418 7963 7321 8302 8216 8582 8582
19 10344 4711 10323 5567 10312 6418
10280 7255
10269 8094 10291 8527
21 13138 5543 13117 6400 13096 7247 13053 8081 13042 8499
23 16115 6344 16093 7199 16051 8042 16029 8461
7
15 4121 3958 4960 4960 5858 5858 6749 6749 7610 7610 8037 8037
17 5785 3877 6123 4842 6565 5821 7073 6792 7669 7669 8052 8052
19 8891 4092 8891 4952 8861 5789 8950 6669 9156 7575 9274 8030
21 11918 5026 11897 5877 11875 6720 11854 7560 11854 7983
23 14980 5868 14959 6719 14916 7558 14916 7985
9
3
15 4666 4362 5174 5174 6002 6002 6823 6823 7632 7632 8037 8037
17 6859 4342 6830 5180 6896 6041 7110 6918 7654 7654 8052 8052
19 9456 4331 9434 5183 9413 6026 9384 6860 9362 7694 9377 8120
21 12186 5140 12154 5988 12132 6831 12111 7673 12089 8082
23 15130 5934 15098 6781 15066 7625 15044 8041
5
15 3834 3810 4681 4681 5557 5557 6418 6418 7257 7257 7669 7669
17 5387 3711 5623 4628 6006 5571 6528 6507 7272 7272 7684 7684
19 8228 3820 8214 4669 8199 5512 8243 6370 8405 7252 8523 7701
21 11062 4676 11040 5525 11019 6364 10997 7201 10987 7615
23 14059 5496 14038 6343 13995 7180 13995 7606
7
15 2900 2900 3996 3996 4960 4960 5873 5873 6756 6756 7183 7183
17 3488 2857 4327 3960 5108 5003 5888 5888 6771 6771 7198 7198
19 6271 3041 6315 3901 6565 4823 6948 5782 7404 6740 7654 7226
21 9606 4099 9584 4940 9584 5784 9606 6634 9670 7076
23 12774 4990 12753 5833 12732 6674 12710 7087
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensible cooling capacity
NB: The values in bold type indicate the rated value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
VED 540/541
Qv [m
3
/h] k (Pc) k (Ps)
Rated speed 1700 1 1
Maximum speed 1500 0.87 0.89
Average speed 1380 0.83 0.85
Minimum speed 1100 0.72 0.72
COOLING CAPACITY CORRECTION FACTORS
