COOLING CAPACITY - VED540 / VED541
Tw [°C] DT [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 3463 3463 4324 4324 5159 5159 5976 5976 6793 6793 7198 7198
17 4724 3433 4894 4322 5262 5221 5991 5991 6808 6808 7213 7213
19 7345 3463 7331 4308 7316 5142 7323 5988 7478 6857 7566 7288
21 10098 4292 10077 5136 10055 5971 10034 6804 10023 7215
23 13042 5095 13010 5936 12989 6777 12967 7190
5
15 2826 2826 3786 3786 4688 4688 5557 5557 6403 6403 6823 6823
17 3253 2766 3945 3790 4695 4695 5564 5564 6418 6418 6837 6837
19 5800 2859 5814 3706 5991 4597 6322 5526 6756 6460 6999 6918
21 8803 3790 8788 4632 8788 5471 8788 6309 8832 6742
23 11832 4630 11832 5480 11790 6308 11790 6729
7
15 1654 1654 2973 2973 4033 4033 4983 4983 5888 5888 6329 6329
17 1658 1658 2988 2988 4040 4040 4997 4997 5903 5903 6337 6337
19 2738 1706 3783 2877 4570 3948 5299 4980 6013 5963 6381 6381
21 6845 3065 6859 3909 7066 4809 7389 5742 7581 6209
23 10334 4078 10323 4917 10312 5753 10291 6161
13
3
15 2576 2576 3459 3459 4309 4309 5137 5137 5954 5954 6359 6359
17 2782 2569 3466 3466 4320 4320 5144 5144 5969 5969 6374 6374
19 5064 2579 5049 3409 5174 4278 5476 5174 5984 5984 6388 6388
21 7860 3437 7846 4274 7831 5101 7816 5928 7853 6356
23 10805 4251 10794 5092 10762 5920 10751 6332
5
15 1751 1751 2855 2855 3798 3798 4688 4688 5549 5549 5976 5976
17 1758 1758 2859 2859 3805 3805 4695 4695 5564 5564 5991 5991
19 2752 1716 3452 2756 4121 3767 4791 4741 5571 5571 5998 5998
21 6271 2859 6271 3695 6403 4562 6683 5474 6845 5928
23 9434 3758 9413 4589 9391 5415 9391 5831
7
15 835 835 1669 1669 3039 3039 4063 4063 5005 5005 5454 5454
17 835 835 1669 1669 3039 3039 4077 4077 5012 5012 5461 5461
19 862 801 1677 1677 3076 3076 4085 4085 5019 5019 5476 5476
21 3179 1785 4077 2880 4828 3920 5520 4937 5844 5429
23 7448 3075 7448 3905 7595 4783 7713 5232
15
3
15 1647 1647 2579 2579 3452 3452 4294 4294 5115 5115 5527 5527
17 1651 1651 2583 2583 3459 3459 4305 4305 5130 5130 5535 5535
19 2406 1592 2911 2546 3518 3499 4313 4313 5137 5137 5549 5549
21 5417 2558 5402 3378 5490 4233 5733 5118 5903 5561
23 8412 3403 8405 4233 8376 5052 8368 5462
5
15 669 669 1810 1810 2874 2874 3805 3805 4688 4688 5122 5122
17 670 670 1810 1810 2877 2877 3812 3812 4695 4695 5130 5130
19 674 674 1825 1825 2885 2885 3820 3820 4710 4710 5137 5137
21 3017 1732 3665 2738 4298 3730 4931 4700 5255 5176
23 6742 2840 6742 3665 6823 4516 6926 4959
7
15 133 133 835 835 1736 1736 3084 3084 4092 4092 4563 4563
17 133 133 835 835 1736 1736 3091 3091 4099 4099 4570 4570
19 133 133 835 835 1743 1743 3098 3098 4107 4107 4578 4578
21 866 788 1795 1778 3187 3100 4143 4143 4592 4592
23 3577 1826 4401 2877 5108 3891 5446 4390
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensible cooling capacity
NB: The values in bold type indicate the rated value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
VED 540/541
Qv [m
3
/h] k (Pc) k (Ps)
Rated speed 1700 1 1
Maximum speed 1500 0.87 0.89
Average speed 1380 0.83 0.85
Minimum speed 1100 0.72 0.72
COOLING CAPACITY CORRECTION FACTORS
