20
IVEDPY 2005 - 4879010_04
COOLING CAPACITY - VED630
Tw [°C] DT [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
5
3
15 11166 9688 11116 11022 11166 11166 11514 11514 12599 12599 13147 13147
17 14407 9638 14378 10999 14349 12341 14320 13677 14276 14276 14291 14291
19 17910 9560 17866 10924 17823 12276 17780 13618 17736 14940 17707 15603
21 21616 10821 21558 12176 21500 13516 21442 14854 21428 15523
23 25582 12040 25553 13410 25466 14741 25437 15412
5
15 9633 8806 9852 9852 10270 10270 10987 10987 12091 12091 12639 12639
17 13060 8884 13031 10238 12988 11574 13046 12943 13191 13191 13335 13335
19 16607 8842 16578 10209 16549 11563 16520 12912 16491 14239 16433 14887
21 20371 10140 20313 11492 20284 12845 20240 14186 20226 14854
23 24395 11396 24337 12745 24279 14089 24250 14757
7
15 7722 7670 8439 8439 9225 9225 10290 10290 11445 11445 12022 12022
17 11106 7832 11086 9180 11265 10594 11624 11624 12101 12101 12420 12420
19 15044 8012 15015 9372 14986 10720 14928 12047 14957 13398 14986 14082
21 18923 9375 18865 10721 18836 12069 18807 13414 18778 14070
23 23005 10667 22976 12028 22919 13369 22890 14035
7
3
15 8668 8273 8787 8787 9265 9265 10370 10370 11464 11464 12002 12002
17 11932 8272 11902 9619 11863 10952 11853 11853 12062 12062 12221 12221
19 15420 8212 15391 9574 15362 10924 15304 12244 15290 13577 15246 14224
21 19126 9486 19068 10833 15304 12244 18981 13507 18967 14174
23 23092 10722 23063 12082 23005 13423 22976 14088
5
15 7155 7155 7782 7782 8688 8688 9832 9832 10957 10957 11504 11504
17 10370 7446 10330 8781 10469 10173 10768 10768 11226 11226 11604 11604
19 13987 7467 13958 8824 13943 10174
13900 11500
13886 12830 13914 13516
21 17765 8786 17736 10144 17707 11487 17649 12809 17635 13473
23 21789 10056 21760 11411 21703 12747 21674 13411
7
15 5573 5573 6707 6707 7921 7921 9126 9126 10290 10290 10867 10867
17 7822 6146 8280 7675 8877 8877 9564 9564 10370 10370 10887 10887
19 12022 6486 12022 7849 11982 9176 12101 10571 12380 12007 12539 12539
21 16115 7967 16086 9316 16057 10652 16028 11984 16028 12654
23 20255 9301 20226 10651 20168 11980 20168 12657
9
3
15 6309 6309 6996 6996 8115 8115 9225 9225 10320 10320 10867 10867
17 9275 6882 9235 8211 9325 9325 9613 9613 10350 10350 10887 10887
19 12785 6865 12756 8216 12727 9552 12689 10873 12659 12195 12679 12679
21 16477 8148 16433 9491 16404 10828 16375 12163 16346 12811
23 20458 9406 20414 10749 20371 12086 20342 12747
5
15 5185 5185 6329 6329 7513 7513 8678 8678 9812 9812 10370 10370
17 7284 5883 7603 7336 8120 8120 8827 8827 9832 9832 10390 10390
19 11126 6055 11106 7400 11086 8736 11146 10098 11365 11365 11524 11524
21 14957 7412 14928 8757 14899 10088 14870 11415 14855 12070
23 19010 8711 18981 10055 18923 11381 18923 12056
7
15 3921 3921 5404 5404 6707 6707 7941 7941 9136 9136 9713 9713
17 4717 4529 5851 5851 6906 6906 7961 7961 9155 9155 9733 9733
19 8479 4821 8538 6183 8877 7645 9394 9166 10011 10011 10350 10350
21 12988 6497 12959 7830 12959 9168 12988 10515 13075 11216
23 17273 7909 17244 9246 17215 10580 17186 11233
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensible cooling capacity
NB: The values in bold type indicate the rated value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
VED 630
Qv [m
3
/h] k (Pc) k (Ps)
Rated speed 2450 1 1
Maximum speed 2210 0.90 0.90
Average speed 1800 0.77 0.76
Minimum speed 1380 0.64 0.63
COOLING CAPACITY CORRECTION FACTORS
