24
IVEDPY 2005 - 4879010_04
COOLING CAPACITY - VED730
Tw [°C] DT [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
5
3
15 12339 10758 12284 12240 12339 12339 12724 12724 13922 13922 14528 14528
17 15920 10703 15888 12214 15856 13704 15824 15187 15776 15776 15792 15792
19 19791 10616 19743 12130 19695 13632 19647 15122 19599 16590 19567 17326
21 23886 12016 23822 13521 23758 15009 23694 16494 23678 17237
23 28269 13369 28237 14891 28141 16369 28109 17114
5
15 10645 9778 10887 10887 11349 11349 12141 12141 13361 13361 13966 13966
17 14432 9865 14400 11369 14352 12852 14416 14372 14576 14576 14736 14736
19 18351 9818 18319 11337 18287 12840 18255 14338 18223 15811 18159 16531
21 22510 11259 22446 12761 22414 14263 22366 15753 22350 16495
23 26957 12654 26893 14152 26829 15645 26797 16387
7
15 8534 8517 9325 9325 10194 10194 11371 11371 12647 12647 13284 13284
17 12273 8697 12251 10194 12449 11763 12845 12845 13372 13372 13724 13724
19 16624 8897 16592 10407 16560 11904 16496 13377 16528 14877 16560 15637
21 20911 10411 20847 11905 20815 13402 20783 14895 20751 15624
23 25422 11846 25390 13357 25326 14845 25294 15585
7
3
15 9578 9187 9710 9710 10238 10238 11459 11459 12669 12669 13262 13262
17 13185 9185 13152 10682 13108 12162 13097 13097 13328 13328 13504 13504
19 17040 9119 17008 10631 16976 12130 16912 13597 16896 15076 16848 15794
21 21135 10534 21071 12029 16912 13597 20975 14999 20959 15740
23 25518 11907 25486 13416 25422 14905 25390 15644
5
15 7907 7907 8599 8599 9600 9600 10865 10865 12108 12108 12713 12713
17 11459 8268 11415 9751 11569 11296 11899 11899 12405 12405 12823 12823
19 15456 8292 15424 9798 15408 11298
15360 12770
15344 14247 15376 15009
21 19631 9756 19599 11264 19567 12755 19503 14224 19487 14960
23 24078 11166 24046 12671 23982 14155 23950 14892
7
15 6158 6158 7412 7412 8753 8753 10084 10084 11371 11371 12009 12009
17 8643 6825 9149 8522 9809 9809 10568 10568 11459 11459 12031 12031
19 13284 7203 13284 8716 13240 10189 13372 11738 13680 13333 13856 13856
21 17807 8847 17775 10345 17743 11828 17711 13308 17711 14051
23 22382 10328 22350 11827 22286 13303 22286 14055
9
3
15 6972 6972 7731 7731 8968 8968 10194 10194 11404 11404 12009 12009
17 10249 7642 10205 9118 10304 10304 10623 10623 11437 11437 12031 12031
19 14128 7623 14096 9123 14064 10607 14021 12074 13988 13542 14010 14010
21 18207 9048 18159 10539 18127 12024 18095 13506 18063 14226
23 22606 10445 22558 11936 22510 13421 22478 14154
5
15 5729 5729 6994 6994 8303 8303 9589 9589 10843 10843 11459 11459
17 8050 6533 8402 8146 8973 8973 9754 9754 10865 10865 11481 11481
19 12295 6724 12273 8217 12251 9701 12317 11213 12559 12559 12735 12735
21 16528 8231 16496 9724 16464 11202 16432 12676 16416 13403
23 21007 9673 20975 11165 20911 12637 20911 13387
7
15 4332 4332 5971 5971 7412 7412 8775 8775 10095 10095 10733 10733
17 5212 5029 6466 6466 7632 7632 8797 8797 10117 10117 10755 10755
19 9369 5353 9435 6866 9809 8489 10381 10178 11063 11063 11437 11437
21 14352 7214 14320 8695 14320 10180 14352 11676 14448 12454
23 19087 8783 19055 10268 19023 11748 18991 12474
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensible cooling capacity
NB: The values in bold type indicate the rated value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
VED 730
Qv [m
3
/h] k (Pc) k (Ps)
Rated speed 2800 1 1
Maximum speed 2410 0.90 0.90
Average speed 2040 0.79 0.78
Minimum speed 1640 0.68 0.66
COOLING CAPACITY CORRECTION FACTORS
