AERMEC VED - Page 82

25
IVEDPY 2005 - 4879010_04
COOLING CAPACITY - VED730
Tw [°C] DT [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 5174 5174 6460 6460 7709 7709 8929 8929 10150 10150 10755 10755
17 7058 6043 7313 7313 7863 7863 8951 8951 10172 10172 10777 10777
19 10975 6095 10953 7582 10931 9051 10942 10540 11173 11173 11305 11305
21 15088 7555 15056 9041 15024 10510 14992 11976 14976 12700
23 19487 8968 19439 10448 19407 11929 19375 12656
5
15 4222 4222 5658 5658 7005 7005 8303 8303 9567 9567 10194 10194
17 4860 4860 5894 5894 7016 7016 8314 8314 9589 9589 10216 10216
19 8665 5033 8687 6523 8951 8092 9446 9446 10095 10095 10458 10458
21 13152 6671 13130 8153 13130 9630 13130 11104 13196 11868
23 17679 8150 17679 9645 17615 11103 17615 11844
7
15 2472 2472 4442 4442 6026 6026 7445 7445 8797 8797 9457 9457
17 2477 2477 4464 4464 6037 6037 7467 7467 8819 8819 9468 9468
19 4090 3003 5652 5064 6829 6829 7918 7918 8984 8984 9534 9534
21 10227 5394 10249 6881 10557 8464 11041 10107 11327 10928
23 15440 7178 15424 8654 15408 10127 15376 10845
13
3
15 3849 3849 5168 5168 6438 6438 7676 7676 8896 8896 9501 9501
17 4156 4156 5179 5179 6455 6455 7687 7687 8918 8918 9523 9523
19 7566 4540 7544 6000 7731 7531 8182 8182 8940 8940 9545 9545
21 11745 6050 11723 7523 11701 8979 11679 10435 11734 11188
23 16144 7482 16128 8963 16080 10419 16064 11146
5
15 2616 2616 4266 4266 5674 5674 7005 7005 8292 8292 8929 8929
17 2627 2627 4272 4272 5685 5685 7016 7016 8314 8314 8951 8951
19 4112 3020 5157 4851 6158 6158 7159 7159 8325 8325 8962 8962
21 9369 5032 9369 6505 9567 8030 9985 9635 10227 10227
23 14096 6615 14064 8077 14032 9531 14032 10263
7
15 1248 1248 2494 2494 4541 4541 6070 6070 7478 7478 8149 8149
17 1248 1248 2494 2494 4541 4541 6092 6092 7489 7489 8160 8160
19 1287 1287 2505 2505 4596 4596 6103 6103 7500 7500 8182 8182
21 4750 3141 6092 5069 7214 6900 8248 8248 8731 8731
23 11129 5412 11129 6873 11349 8418 11525 9209
15
3
15 2461 2461 3854 3854 5157 5157 6416 6416 7643 7643 8259 8259
17 2466 2466 3860 3860 5168 5168 6433 6433 7665 7665 8270 8270
19 3596 2802 4349 4349 5256 5256 6444 6444 7676 7676 8292 8292
21 8094 4502 8072 5946 8204 7451 8566 8566 8819 8819
23 12570 5990 12559 7452 12515 8892 12504 9614
5
15 999 999 2704 2704 4294 4294 5685 5685 7005 7005 7654 7654
17 1002 1002 2704 2704 4299 4299 5696 5696 7016 7016 7665 7665
19 1007 1007 2727 2727 4310 4310 5707 5707 7038 7038 7676 7676
21 4508 3049 5476 4819 6422 6422 7368 7368 7852 7852
23 10073 5000 10073 6450 10194 7948 10348 8728
7
15 198 198 1248 1248 2594 2594 4607 4607 6114 6114 6818 6818
17 198 198 1248 1248 2594 2594 4618 4618 6125 6125 6829 6829
19 198 198 1248 1248 2605 2605 4629 4629 6136 6136 6840 6840
21 1294 1294 2682 2682 4761 4761 6191 6191 6862 6862
23 5344 3214 6576 5065 7632 6849 8138 7727
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensible cooling capacity
NB: The values in bold type indicate the rated value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
VED 730
Qv [m
3
/h] k (Pc) k (Ps)
Rated speed 2800 1 1
Maximum speed 2410 0.90 0.90
Average speed 2040 0.79 0.78
Minimum speed 1640 0.68 0.66
COOLING CAPACITY CORRECTION FACTORS
